110 kW Screw Air Compressor | Two-stage compression + IE3 energy efficiency—the top choice for industrial air applications
110 kW Screw Air Compressor | Two-stage compression + IE3 energy efficiency—the top choice for industrial air applications
110 kW Screw Air Compressor | Two-stage compression + IE3 energy efficiency—the top choice for industrial air applications
110 kW Screw Air Compressor | Two-stage compression + IE3 energy efficiency—the top choice for industrial air applications
110 kW Screw Air Compressor | Two-stage compression + IE3 energy efficiency—the top choice for industrial air applications
110 kW Screw Air Compressor | Two-stage compression + IE3 energy efficiency—the top choice for industrial air applications
110 kW Screw Air Compressor | Two-stage compression + IE3 energy efficiency—the top choice for industrial air applications
110 kW Screw Air Compressor | Two-stage compression + IE3 energy efficiency—the top choice for industrial air applications
Specifications
Payment Terms :
TT/LC,Western Union,D/P,D/A
Price :
Negotiable
Model Number :
AGCD-110II VP
Cooling type :
Air cooling
Supply Ability :
2,000-3,000 per month
Packaging Details :
wooden case
MOQ :
1 unit
Delivery Time :
5-15 days
Air capacity（m3/min） :
6.6~24.86
Certification :
ISO、CE、TUV
Working Pressure :
0.7~1.3MPa
Place of Origin :
made in China
Driven type :
Direct driven
Brand Name :
AIRERA
Motor power :
110KW
Description
AIRERA 110 kW Two-Stage Screw Air Compressor: IE3 Premium Efficiency, The Ultimate Choice for Industrial Air Applications

The AIRERA 110 kW two-stage screw air compressor is engineered for modern industries demanding ultimate energy efficiency and high reliability. Featuring industry-leading two-stage compression technology, it significantly reduces compression ratios and internal leakage compared to single-stage models, drastically boosting air output. Paired with a premium IE3 energy-efficient motor, it delivers a continuous power supply while achieving remarkably lower energy consumption.

Built for stable operation and low noise, this compressor excels during long hours of continuous operation in harsh industrial environments. Whether in automotive manufacturing, chemical processing, or heavy industry, AIRERA stands as your premier choice for optimizing production costs and achieving green manufacturing.

  • Noise reduction sheet metal design

Multiple noise reduction designs, calculated according to noise science, with special flame-retardant and sound-absorbing cotton inside to reduce unit noise.

110 kW Screw Air Compressor | Two-stage compression + IE3 energy efficiency—the top choice for industrial air applications

  • Industry-leading air host

The air compression chamber is completely separated from the oil chamber. The air side adopts a non-abrasive sealing system with a spring-loaded metal ring, and the lubricating oil side adopts a non-abrasive sealing system with a copper labyrinth seal. The two do not contact.

110 kW Screw Air Compressor | Two-stage compression + IE3 energy efficiency—the top choice for industrial air applications


  • Independent air intake system

Independent air intake ensures that the intake air temperature is equal to the ambient temperature. Large-capacity air filter is used to achieve better filtering effect, lower intake pressure loss, and energy saving and high efficiency. Maintenance and replacement are more convenient.

110 kW Screw Air Compressor | Two-stage compression + IE3 energy efficiency—the top choice for industrial air applications


Technical Specifications -AGCD-110II VP Diesel Portable Compressor
AGCD-110II VP Diesel Portable Compressor Parameters
ITEM UNIT MODEL AGCD-110II VP
Air capacity m³/min 9.94-24.86|9.00-22.50|7.80-19.50|6.60-16.50
Working pressure MPa 0.7~1.3
Compressor type
Oil inject dual stage screw compressor
Cooling type

Air cooling
Driven type
Direct driven
Inlet status Temperature ℃ ≤45
Inlet status Pressure MPa Atmospheric pressure
Inlet status Relative humidity
≤90%
Noise Level dB(A) ≤79
Residual oil content ppm ≤2
Drive rotor speed rpm 1500
Compressed air outlet temperature ℃ Ambient temperature＋10
Cooling air flow m3/hr 12200
Control mode
Intelligent controller
Safety valve set pressure MPa 0.77-1.43
Lubricating oil volume L 70
Lubricating oil brand
ROTORCOMP
Compressed air outlet connection
G2-1/2
Dimension L mm 2540
Dimension W mm 1640
Dimension H mm 1800
Net Weight kg 1760
Motor Model
YPM-280M2-8
Motor Speed rpm 1500
Motor Rated Power KW 110
Motor Service factor
1.2
Motor Protection type
IP55
Motor Efficiency
IE3
Motor Startup mode
Frequency conversion starting
Motor Voltage V 380(Special on request)
Motor Frequency Hz 80-200
Motor Rated current A 203
Motor Weight of motor kg 922
110 kW Screw Air Compressor | Two-stage compression + IE3 energy efficiency—the top choice for industrial air applications
CALT AGCD-110II VP Diesel Portable Compressor: Frequently Asked Questions (FAQ)
What tangible benefits can the equipped IE3 premium efficiency motor bring to industrial production?

The IE3 motor meets the international premium efficiency standards, featuring extremely low internal losses. For high-power industrial equipment like a 110 kW unit, compressors often run 24/7 year-round. IE3 motors improve operational efficiency by 2% to 4% compared to standard motors. Combined with the two-stage air end, the energy savings can fully recoup the machine's initial investment cost within 2-3 years, making it ideal for green manufacturing and low-carbon emissions.

For a large power demand like 110 kW, how does AIRERA perform in terms of smart control and VFD energy saving?
The AIRERA 110 kW model is equipped with a modern intelligent control system supporting real-time monitoring, remote linkage, and fault pre-warnings. We offer an optional advanced Variable Frequency Drive (VFD), which works in tandem with the IE3 motor to automatically adjust the motor speed based on the factory's actual air demand. This eliminates energy waste caused by frequent idling, boosting comprehensive energy savings by an additional 30% or more.
How is the stability and lifespan of this air compressor guaranteed under continuous heavy-duty, extreme industrial environments?

This model is purpose-built for heavy industry. Two-stage compression achieves a lower near-isothermal compression process, resulting in lower operating temperatures and preventing lubricating oil from high-temperature degradation. Meanwhile, the IE3 motor features excellent insulation and protection ratings (IP55). Paired with AIRERA's highly efficient cooling system, the machine maintains a stable, continuous 24/7 constant pressure output even in harsh environments up to 45°C.
