18.5 kW Oil-Lubricated Two-Stage Screw Air Compressor: Smart Control, Low Noise, Low Fuel Consumption, Industrial Grade
18.5 kW Oil-Lubricated Two-Stage Screw Air Compressor: Smart Control, Low Noise, Low Fuel Consumption, Industrial Grade
18.5 kW Oil-Lubricated Two-Stage Screw Air Compressor: Smart Control, Low Noise, Low Fuel Consumption, Industrial Grade
18.5 kW Oil-Lubricated Two-Stage Screw Air Compressor: Smart Control, Low Noise, Low Fuel Consumption, Industrial Grade
18.5 kW Oil-Lubricated Two-Stage Screw Air Compressor: Smart Control, Low Noise, Low Fuel Consumption, Industrial Grade
18.5 kW Oil-Lubricated Two-Stage Screw Air Compressor: Smart Control, Low Noise, Low Fuel Consumption, Industrial Grade
18.5 kW Oil-Lubricated Two-Stage Screw Air Compressor: Smart Control, Low Noise, Low Fuel Consumption, Industrial Grade
18.5 kW Oil-Lubricated Two-Stage Screw Air Compressor: Smart Control, Low Noise, Low Fuel Consumption, Industrial Grade
Specifications
Brand Name :
AIRERA
Model Number :
LGCD-15II
Certification :
ISO、CE、TUV
Place of Origin :
made in China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
TT/LC,Western Union,D/P,D/A
Supply Ability :
2,000-3,000 per month
Delivery Time :
5-15 days
Packaging Details :
wooden case
Air capacity（m3/min） :
2.6~3.47
Working Pressure :
0.7~1.3MPa
Cooling type :
Air cooling
Driven type :
Direct driven
Motor power :
18.5KW
Description
AIRERA 18.5 kW Industrial Two-Stage Oil-Lubricated Screw Air Compressor: Smart Control, Low Noise & Low Fuel Consumption

Smart Manufacturing with Minimum Waste. The AIRERA 18.5 kW industrial-grade two-stage oil-lubricated screw air compressor is built for modern factories seeking maximum efficiency. Featuring advanced two-stage compression, it delivers superior air output with remarkable energy savings. Its smart microcomputer controller ensures precision air management and automated operation. With a fully enclosed silent canopy and a premium oil-gas separation system, it guarantees ultra-low noise levels and minimal oil consumption. Upholding AIRERA’s rigorous standards, this unit is your ultimate choice for a green, quiet, and highly productive workshop.

  • Direct driven

Big rotors and low speed;Lower maitainace cost.


18.5 kW Oil-Lubricated Two-Stage Screw Air Compressor: Smart Control, Low Noise, Low Fuel Consumption, Industrial Grade
  • Cooling air flow

A separate generously sized cooling air fan provides several times the minimum required volume for the motors.The motor is sited in the main cooling air intake flow, which means:the coolest air crosses the motor first, increased service life.The ambient cooling air also cools the switch cabinet and the electrical components , which ensures:low component temperature and extended service life.


18.5 kW Oil-Lubricated Two-Stage Screw Air Compressor: Smart Control, Low Noise, Low Fuel Consumption, Industrial Grade

  • Fan motor

Motor IP class : IP44;Motor without self cooled function;Motor without service factor;Low cooling air flow;Lower cooling air pressure.


18.5 kW Oil-Lubricated Two-Stage Screw Air Compressor: Smart Control, Low Noise, Low Fuel Consumption, Industrial Grade


Technical Specifications -LGCD-18.5II Diesel Portable Compressor
LGCD-18.5II Diesel Portable Compressor Parameters
ITEM UNIT MODEL LGCD-18.5II
Air capacity m³/min 2.6`3.47
Working pressure MPa 0.7~1.3
Compressor type
Oil inject dual stage screw compressor
Cooling type

Air cooling
Driven type
Direct driven
Inlet status Temperature ℃ ≤45
Inlet status Pressure MPa Atmospheric pressure
Inlet status Relative humidity
≤90%
Noise Level dB(A) ≤72
Residual oil content ppm ≤2
Drive rotor speed rpm 1475
Compressed air outlet temperature ℃ Ambient temperature＋10
Cooling air flow m3/hr 7200
Control mode
Intelligent controller
Safety valve set pressure MPa 0.77-1.43
Lubricating oil volume L 15
Lubricating oil brand
ROTORCOMP
Compressed air outlet connection
G1
Dimension L mm 1400
Dimension W mm 850
Dimension H mm 1200
Net Weight kg 405
Motor Model
Y2160L-4
Motor Speed rpm 1475
Motor Rated Power KW 18.5
Motor Service factor
1.2
Motor Protection type
IP55
Motor Efficiency
IE3
Motor Startup mode
ʏ-Δ starting
Motor Voltage V 380(Special on request)
Motor Frequency Hz 50(Special on request)
Motor Rated current A 35.5
Motor Weight of motor kg 145
18.5 kW Oil-Lubricated Two-Stage Screw Air Compressor: Smart Control, Low Noise, Low Fuel Consumption, Industrial Grade
CALT LGCD-18.5II Diesel Portable Compressor: Frequently Asked Questions (FAQ)
This unit is labeled "Industrial Grade." What makes it so durable for heavy-duty use?
This compressor is engineered for continuous 24/7 non-stop operation. From the high-temperature heavy-duty bearings and IP55 high-protection motors to the robust all-steel piping design (eliminating aging and oil leaks), every component is strictly selected for industrial rigor. The core AIRERA air end is designed for a lifespan of tens of thousands of hours, effortlessly handling harsh, dusty, or high-temperature factory environments.
What role does two-stage compression play in an oil-lubricated model?
In oil-injected screw compressors, oil injection functions to cool, seal, and lubricate. Two-stage compression significantly lowers air temperature during the process by inter-stage cooling with air-oil mixing. This brings the compression closer to energy-saving "isothermal compression" and prevents the lubricant from carbonizing or degrading due to high heat, drastically extending the lifespan of both the air end and the oil.
What are the practical benefits of the "Low Fuel Consumption" feature for a factory?

AIRERA utilizes a multi-stage precision oil-gas separation system that restricts exhaust oil carryover to an absolute minimum (typically less than 3ppm). This means you don't have to top up compressor oil frequently, saving significantly on lubricant costs. More importantly, it extends the lifespan of downstream line filters and delivers much cleaner compressed air.
