OMRON E3Z-T61 Photoelectric Sensor | 15m Through-beam, NPN, 24V DC, IP67
OMRON E3Z-T61 Photoelectric Sensor | 15m Through-beam, NPN, 24V DC, IP67
OMRON E3Z-T61 Photoelectric Sensor | 15m Through-beam, NPN, 24V DC, IP67
OMRON E3Z-T61 Photoelectric Sensor | 15m Through-beam, NPN, 24V DC, IP67
Specifications
Brand Name :
OMRON
Model Number :
E3Z-T61
Certification :
ATEX
Place of Origin :
ID
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T,XT,ALIPAY
Supply Ability :
100pcs per month
Delivery Time :
Negotiable
Packaging Details :
carton
Power Supply :
1
Ambient Temperature :
-
Electrical Rating :
G
Certifications :
S
Description

OMRON E3Z-T61 Photoelectric Sensor | 15m Through-beam, NPN, 24V DC, IP67

OMRON E3Z-T61 through-beam photoelectric sensor specifications. 15m range, NPN output, 12-24V DC, IP67, for industrial automation object detection.

Product Overview

The OMRON E3Z-T61 is a compact, square-bodied through-beam photoelectric sensor​ consisting of a matched emitter (E3Z-T61-L) and receiver (E3Z-T61-D) pair. It features a 15m sensing distance, infrared LED light source (870nm), and NPN open-collector output. Designed for reliable object detection in industrial automation, it operates on 12-24V DC and is housed in an IP67-rated PBT enclosure.

Technical Specifications (Sensing & Electrical)

Parameter

Specification

Manufacturer​

OMRON

Series​

E3Z (Compact Square Type)

Model​

E3Z-T61 (Set includes T61-L Emitter & T61-D Receiver)

Sensing Method​

Through-beam (Emitter + Receiver)

Sensing Distance​

15 m (Max.)

Light Source​

Infrared LED (870 nm)

Power Supply Voltage​

12 to 24 V DC ±10%

Current Consumption​

Emitter: ≤15 mA; Receiver: ≤20 mA

Output Type​

NPN Open Collector

Max. Load Current​

100 mA

Operation Mode​

Light-ON / Dark-ON (Selectable)

Technical Specifications (Mechanical & Environmental)

Parameter

Specification

Connection​

Pre-wired Cable (2 m length)

Housing Material​

PBT (Polybutylene Terephthalate)

Lens Material​

Denatured Polyarylate

Protection Rating​

IP67 (IEC Standard)

Operating Temperature​

-25°C to +55°C

Response Time​

1 ms max. (ON/OFF)

Standard Object​

Ø12 mm opaque

Indicator Lights​

Power (Orange), Stability (Green), Operation (Orange)

Weight (Set)​

Approx. 120 g

Key Features

  • Long-Range Detection:​ 15m sensing distance for wide application coverage.

  • High-Speed Response:​ 1ms response time for fast-moving object detection.

  • Robust Construction:​ IP67-rated housing resistant to water and dust ingress.

  • Easy Installation:​ Square body design with M4 mounting holes and 2m fixed cable.

  • Interference Resistance:​ Infrared light source with modulated beam for stable operation.

Applications

  • Object presence detection on conveyors

  • Material handling and packaging machinery

  • Automated assembly line counting

  • Door and gate safety monitoring
