Schneider Electric LC1D11500M7C | TeSys D 3P Contactor 115A 220V AC Coil
Schneider Electric LC1D11500M7C | TeSys D 3P Contactor 115A 220V AC Coil
Schneider Electric LC1D11500M7C | TeSys D 3P Contactor 115A 220V AC Coil
Schneider Electric LC1D11500M7C | TeSys D 3P Contactor 115A 220V AC Coil
Schneider Electric LC1D11500M7C | TeSys D 3P Contactor 115A 220V AC Coil
Schneider Electric LC1D11500M7C | TeSys D 3P Contactor 115A 220V AC Coil
Specifications
Brand Name :
Schneider Electric
Model Number :
LC1D11500M7C
Certification :
ATEX
Place of Origin :
CN
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T,XT,ALIPAY
Supply Ability :
100pcs per month
Delivery Time :
Negotiable
Packaging Details :
carton
Power Supply :
1
Ambient Temperature :
-
Electrical Rating :
G
Certifications :
S
Description

Schneider Electric LC1D11500M7C | TeSys D 3P Contactor 115A 220V AC Coil

Schneider Electric LC1D11500M7C TeSys D contactor. 3-pole, 115A AC-3 rating, 220V 50/60Hz coil, 55kW motor control. DIN rail or plate mount, modular auxiliary contact design.

Product Overview

The Schneider Electric LC1D11500M7C​ is a 3-pole (3 NO) power contactor​ from the TeSys D series. Rated for 115 A (AC-3), it is designed for heavy-duty motor starting and switching of 3-phase loads up to 55 kW (400V). This variant features a 220V AC 50/60 Hz control coil​ and a modular design that allows for the addition of auxiliary contact blocks (sold separately). It is commonly used in industrial motor control centers, pump control panels, and HVAC systems.

Technical Specifications (Electrical & Ratings)

Parameter

Specification

Manufacturer / Series​

Schneider Electric / TeSys D (LC1D)

Model Number​

LC1D11500M7C

Product Type​

3-Pole Electromagnetic Contactor

Rated Operational Current (Ie)​

115 A​ (AC-3, 400V)

Rated Voltage (Ue)​

Up to 690 V AC​ (50/60 Hz)

Control Coil Voltage​

220 V AC​ (50/60 Hz)

Motor Power (AC-3)​

30 kW (230V) / 55 kW (400V)​ / 75 kW (690V)

Utilization Category​

AC-1, AC-3 (Motor), AC-4 (Intermittent)

Auxiliary Contacts​

None (00)​ (Requires add-on blocks e.g., LADN**)

Technical Specifications (Mechanical & Environmental)

Parameter

Specification

Poles / Contact Configuration​

3 NO (Main Contacts)

Mounting​

DIN Rail (35mm) or Panel Plate

Terminal Type​

Screw Clamp (Power & Control)

Wire Range (Power)​

10 – 120 mm² (Flexible/Solid)

Mechanical Life​

8 – 10 Million cycles

Electrical Life (AC-3)​

~0.9 Million cycles

IP Rating​

IP20 (Enclosure required)

Operating Temperature​

-25 °C to +60 °C

Standards​

IEC 60947-4-1, UL 508, CCC

Key Features

  • High-Current Capacity:​ Handles motor loads up to 115A continuously, suitable for large pumps and compressors.

  • Modular Expandability:​ "00" suffix indicates no built-in auxiliaries; side or front-mounted contact blocks (e.g., LADN11) can be added for control signaling.

  • Wide Voltage Coil:​ 220V AC coil is compatible with standard control circuit voltages and tolerant of voltage fluctuations.

  • Robust Construction:​ High electrical endurance and screw terminals designed for secure high-current connections.

Applications

  • Heavy-duty motor starters for industrial machinery

  • Pump and fan control in HVAC systems

  • Main contactor in MCC (Motor Control Center) buckets

  • Automatic transfer switches and power distribution panels
