Schneider Electric LRD21 | TeSys LRD Thermal Overload Relay 12-18A Class 10A
Schneider Electric LRD21 | TeSys LRD Thermal Overload Relay 12-18A Class 10A
Schneider Electric LRD21 | TeSys LRD Thermal Overload Relay 12-18A Class 10A
Schneider Electric LRD21 | TeSys LRD Thermal Overload Relay 12-18A Class 10A
Specifications
Brand Name :
Schneider Electric
Model Number :
LRD21
Certification :
ATEX
Place of Origin :
FR
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T,XT,ALIPAY
Supply Ability :
100pcs per month
Delivery Time :
Negotiable
Packaging Details :
carton
Power Supply :
1
Ambient Temperature :
-
Electrical Rating :
G
Certifications :
S
Description

Schneider Electric LRD21 | TeSys LRD Thermal Overload Relay 12-18A Class 10A

Schneider Electric LRD21 (TeSys LRD) thermal overload relay. 12-18A adjustable range, Class 10A trip, 690V AC, 1NO+1NC contacts. For motor protection with LC1D contactors.

Product Overview

The Schneider Electric LRD21​ is a thermal overload relay​ from the TeSys LRD series​ (also known as TeSys Deca). It provides motor protection​ (overload, phase unbalance) for 3-phase AC motors in the 12–18 A full load current range. Designed for direct mounting under TeSys D contactors (e.g., LC1D18 to LC1D38), it features ambient temperature compensation, manual reset, and a compact form factor for industrial control panels.

Technical Specifications (Electrical & Protection)

Parameter

Specification

Manufacturer / Series​

Schneider Electric / TeSys LRD (Deca)

Model / Part Number​

LRD21

Product Type​

Thermal Overload Relay (Differential, Bi-metallic)

Rated Operational Voltage (Ue)​

690 V AC​ (50/60 Hz, 0–400 Hz range)

Current Setting Range (Ir)​

12 – 18 A​ (Adjustable via dial)

Trip Class​

Class 10A​ (per IEC 60947-4-1)

Phase Failure Sensitivity​

Trips at ~130% Ir on two phases

Auxiliary Contacts​

1 NO + 1 NC​ (Signaling Circuit)

Control Circuit Rating​

1.5 A at 240V AC-15; 0.1 A at 250V DC-13

Technical Specifications (Mechanical & Environmental)

Parameter

Specification

Compatible Contactors​

LC1D18, LC1D25, LC1D32, LC1D38 (TeSys D)

Mounting​

Direct under contactor, DIN rail, or plate

Connection Type​

Screw Clamp Terminals

Terminal Wire Range​

Power: 1.5–10 mm²; Control: 1–2.5 mm²

Dimensions (W×H×D)​

45 × 66 × 70 mm​

IP Rating​

IP20

Operating Temperature​

-20 °C to +60 °C (with compensation)

Reset Type​

Manual (Blue push-button), Red stop button

Key Features

  • Class 10A Tripping:​ Fast response (≈10 seconds) at 7.2× Ir for motor stall protection.

  • Ambient Compensation:​ Maintains trip accuracy across -20°C to +60°C environments.

  • Visual Trip Indication:​ Clear flag/button indication for quick fault diagnosis.

  • Screw Clamp Reliability:​ Robust terminals for power and control wiring.

Applications

  • Protection of 3-phase AC motors (pumps, fans, conveyors)

  • Industrial machine control panels

  • Motor starter combinations with TeSys D contactors
