Specifications
Brand Name :
ZT
Model Number :
YT28
Certification :
CE ISO
Place of Origin :
China
MOQ :
1PC
Price :
USD500-1000/PC
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
7-15 Work Days
Packaging Details :
Wooden Case
Automatic Grade :
Semiautomatic
Power :
Pneumatic
Air Consumption :
3m3/Min
Transport Package :
Wooden Box
HS Code :
8430390000
Hole Diameter :
<50mm
Wind Pressure :
0.4-0.6MPa
Drilling Depth :
5m
After-sales Service :
Tracking Guidance & Service
Warranty :
One Year
Description

Series of YT Rock Drill Description

Hand Held Rock Drilling Machine can be used to dig dry or wet by horizontal holes, vertical holes or angling holes on medium-hard rock or hard rock. Widely used in mines, railway, irrigation and quarry to drill holes and for the second digging holes.

Technical Parameters of YT Series Of Rock Drill

Machine weight 26 kg
Cylinder diameter 80 mm
Piston stroke 60 mm
Working pressure 0.5-0.6 mpa
Impact frequency ≥34 ≥37 hz
Gas consumption ≤55 ≤81 l/min
Tracheal diameter 25 mm
Water pipe diameter 13 mm-
Drilling head diameter 34-42 mm
Drill tail size (hexagonal × length) 22×108±1 mm

Application of YT Rock Drill

Automatic YT26 Air Leg Pneumatic Rock Drill Hand Held Rock Drilling Machine

Advantages of YT Series Rock Drill:

1. Safe and easy to operate
2. High efficiency and reliability
3. The well-known brand
4. Can be used on all rock formation
5. Fast drilling velocity and energy-saving
6. Low vibration and low noise
7. Wet drilling and easy cleaning of air /water holes
8. Parts highly interchangeable and easy to purchase

YT Series Rock Drill Features

This Series pneumatic rock drill applies to hard rock on the rock drill operation, it has strong adaptability to the working conditions. The product is energy efficient, Its components have a long life and are durable. The machine can be generally used with the same type, it can greatly reduce the customer loss for spare part replacement.

Automatic YT26 Air Leg Pneumatic Rock Drill Hand Held Rock Drilling Machine

Features of YT Series Rock Drill
1. The gas distribution method of rock drill is a bowl-shaped gas valve, which is reasonable in layout and sensitive in
starting.
2. It has the advantages of light weight, fast rock drilling speed, low air consumption, small oscillation, convenient
operation, low failure rate, long life of parts, and good economic benefits.
3. The rock drill has a simple structure, safety and is easy to operate.
