Electric Motor Diesel Water Well Drilling Rig Machine
Electric Motor Diesel Water Well Drilling Rig Machine
Electric Motor Diesel Water Well Drilling Rig Machine
Electric Motor Diesel Water Well Drilling Rig Machine
Electric Motor Diesel Water Well Drilling Rig Machine
Electric Motor Diesel Water Well Drilling Rig Machine
Electric Motor Diesel Water Well Drilling Rig Machine
Electric Motor Diesel Water Well Drilling Rig Machine
Electric Motor Diesel Water Well Drilling Rig Machine
Electric Motor Diesel Water Well Drilling Rig Machine
Specifications
Brand Name :
ZT
Model Number :
ZTJD100/150/180
Certification :
CE ISO
Place of Origin :
China
MOQ :
1PC
Price :
USD2500-3000/PC
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
7-15 Work Days
Packaging Details :
Wooden Case
Drilling depth :
100-200（m）
Weight :
362（kg）
Model :
ZSJD-100/120/150/200
Drilling angle range :
360（°）
Broken way :
Rotary Drill
Drilling diameter :
120-150（mm）
Applicable voltage :
220V/380V
After-sales Service :
Tracking Guidance & Service
Warranty :
One Year
Description

Descriptionof Water Well Drill Machine

Diesel Small tube well drill rig machine Geotechnical hydraulic Mine Underground borehole core Water Well Drilling Rig Machine:

This machine is mainly used for geothermal drilling, farm irrigation, house yard, gardens, and water well drilling, drilling diameter is 70-300mm, and the drilling depth is 80-100m. It also can be used in minor building piling, like farmhouses or factories and so on, the drilling diameter can reach 300mm and the depth less than 10m.

Parameters of Water Well Drill Machine

Rig model ZSJD-100 type Motor Power 4000W
Drill pipe diameter 4.2mm Drilling and crushing method Impact Rotary
Dimensions 80cm*80cm*245cm Drilling depth 100-200M
Drill pipe length 1.5m Pump power 2.2KW
Rig weight 200KG Drilling diameter Within 400mm
Drill pipe replacement method Thread button (automatic double thread) Machine Height 2 meters
Applicable voltage 220V/380V Force 1000KG

Rig model ZTJD-150 type Motor Power 4000W
Drill pipe diameter 50mm Drilling and crushing method Impact Rotary
Dimensions 90cm*90cm*245cm Drilling depth 100-200M
Drill pipe length 1.5m Pump power 2.2KW
Rig weight 250KG Drilling diameter Within 400mm
Drill pipe replacement method Thread button (automatic double thread) Machine Height 2 meters
Applicable voltage 220V/380V/
Gasoline / Diesel		 Force 2000KG

Rig model ZTJD-180 type Motor Power 4000W
Drill pipe diameter 50mm Drilling and crushing method Impact Rotary
Dimensions 100cm*100cm*245cm Drilling depth 100-200M
Drill pipe length 1.5m Pump power 2.2KW
Rig weight 290KG Drilling diameter Within 500mm
Drill pipe replacement method Thread button (automatic double thread) Machine Height 2 meters
Applicable voltage 220V/380V/
Gasoline / Diesel		 Force 2000KG

Electric Motor Diesel Water Well Drilling Rig Machine

Features of Water Well Drill Machine

The diesel engines power the drilling rigs. The drilling diameter can reach 50-450mm. It is equipped with diamond drill bits and mud pumps for drilling with a depth of up to 150 meters. Easy to move, suitable for your soil layer, quicksand layer, a small amount of rock layer, pebbles, etc.

Application of Cheap Borehole Drilling Machine /water well drilling rig for Sale 200m:

This machine is mainly used in geothermal drilling, farm irrigation, house yard, gardens, and minor building piling, drilling diameter is 70-350mm, and the drilling depth is within 200m.
