Factory Production Domestic Waste Water Treatment Plant Shipboard Wastewater Treatment Equipment
Factory Production Domestic Waste Water Treatment Plant Shipboard Wastewater Treatment Equipment
Factory Production Domestic Waste Water Treatment Plant Shipboard Wastewater Treatment Equipment
Factory Production Domestic Waste Water Treatment Plant Shipboard Wastewater Treatment Equipment
Specifications
Brand Name :
Zhongqiao Enlightenment
Model Number :
WSZ -4
Certification :
SGS，ISO
Place of Origin :
Shandong，China
MOQ :
1 Set
Price :
4600USD-8400USD
Payment Terms :
D/A,L/C,D/P,T/T,Western Union
Supply Ability :
120Set Per Month
Delivery Time :
15-30 working days
Packaging Details :
container or customized
Description

Factory Production or Domestic Water Treatment Plant, Shipboard Wastewater Treatment Equipment

Introduction

Zhongqiao Enlightenmenti Carbon Steel Series Integrated Wastewater Treatment Equipment is available in various forms such as Zhongqiao Box, Flat Plate, Container, Submarine, and Assembled. The mainstream processes for the equipment include AO, AO+MBR, etc.
Factory Production Domestic Waste Water Treatment Plant Shipboard Wastewater Treatment Equipment

Technical Features

The Zhongqiao Enlightenment technology team is equipped with process engineers, civil engineers, automation design engineers, mechanical design engineers, etc. They have outsourced various complex structural processes, have a thorough understanding of the design concepts of each design process, and improve and optimize them based on actual operating experience.

  1. The three core mode of "A2O+MBBR+efficient sedimentation+deep filtration" ensures stable effluent to the greatest extent possible；
  2. Polyurethane Biocarrier (MBBR), maintenance free, high load,Save investment costs；
  3. 55-60 ° scientific mud hopper design, no sludge accumulation, smooth discharge；
  4. 24-hour continuous automatic operation, no need to stop and backwash；
  5. 12 years of experience accumulation and professional structural design ensure that the equipment is sturdy and reliable, and there is no risk in all working conditions；
  6. Equipped with a fully automatic electrical control system and equipment fault alarm system, it can be remotely controlled to achieve unmanned operation.

Factory Production Domestic Waste Water Treatment Plant Shipboard Wastewater Treatment Equipment
Factory Production Domestic Waste Water Treatment Plant Shipboard Wastewater Treatment Equipment

modelWater treatment capacity (m³/d)outline dimensionweight of
equipment		running
weight		installed powerPower
consumption		running expenserunning expenseCable specificationsfloor space
L x W x H (mm)(t)(t)(kW)(kW)(Yuan/ton of water)(CNY/day)(mm²)(m²)
MBR-0.2552720×1090×21601.187.585.3653.2454.0820.412.519.38
MBR-0.5103440×1090×21601.359.455.3653.2452.0420.412.520.75
MBR-1203890×1610×21601.8315.367.1654.1451.1422.87424.26
MBR-1.25305340×1610×21602.2320.807.274.250.9227.73428.10
MBR-1.67404910×2040×21602.4524.097.874.550.8734.78431.02
MBR-2506360×2040×21603.5531.577.874.550.7034.78439.97
MBR-2.5606360×2040×26604.0538.567.874.550.6740.07439.97
MBR-3707090×2040×26604.3642.838.635.310.5740.07442.84
MBR-3.5806890×2540×26604.9151.4610.236.110.5846.12448.63
MBR-41008340×2540×26605.6061.9511.736.860.6059.62453.93
MBR-51209060×2540×28606.2172.0313.737.860.7691.58658.51
MBR-615011230×2540×28607.6289.2018.8211.070.6191.58667.40
MBR-717010510×2930×28608.0496.1118.8211.070.5491.58670.29
MBR-820012680×2930×28609.19115.4521.0212.570.51101.261080.65
MBR-1025015580×2930×286011.16141.7226.0715.270.51127.1810101.15
MBR-12.53009780×2930×2860
(in two groups)		14.49178.4026.2515.450.45133.6310117.81
MBR-1536011230×2930×2860
(in two groups)		16.02204.2334.6520.350.48171.9416131.31
MBR-1740012680×2930×2860
(in two groups)		17.56230.0735.8521.150.45179.3116144.30
MBR-2050015580×2930×2860
(in two groups)		21.45282.5639.4522.950.36179.3116171.30
