ZH127 Series 10 Pin Straight Bayonet Female Cable Connector

Product Description

The ZH127 Series 10 Pin Straight Bayonet Female Connector is designed based on Russian connector technology, providing stable and reliable electrical connections for low-frequency electronic systems. Engineered for both AC and DC circuits, this connector supports signal transmission frequencies up to 3 MHz and operating voltages up to 700 V (amplitude), making it suitable for a wide range of industrial electrical applications.

Featuring a compact straight cable-mount structure, the ZH127 connector combines convenient installation with dependable connection performance. The bayonet coupling mechanism enables quick mating and secure locking, while multi-level key positioning helps ensure accurate alignment and prevents incorrect insertion. The connector consists of plugs and sockets, with the plug equipped with a metal tail attachment for improved cable protection and mechanical stability.

With aluminum alloy housing, high-performance bakelite insulation, and gold/silver-plated contacts, the ZH127 Series provides excellent electrical insulation, corrosion resistance, and long-term operational reliability. It is interchangeable and intermateable with connectors including OHS-BC, ONTs-BS, SNTs127, and SNC127, offering a practical replacement solution for compatible equipment systems.

Key Features

-- Designed according to Russian connector technology standards

-- Supports AC and DC circuit applications

-- Bayonet locking structure for fast and secure connection

-- Multi-level key positioning improves mating accuracy

-- Gold/silver-plated contacts provide stable electrical performance

-- Straight cable mounting design simplifies installation

-- Aluminum alloy shell offers excellent mechanical protection

-- Bakelite insulation ensures reliable electrical isolation

-- Compatible with multiple connector series for replacement applications

Working Principle

The ZH127 connector transfers electrical signals through precision-machined contacts connected by solder termination. When the plug and socket are aligned according to the key positioning structure, the bayonet coupling rotates and locks the two components together, maintaining stable contact pressure between the conductive terminals. The internal insulation system separates individual contacts, while the metal shell protects the connection from external mechanical influence and environmental conditions.

Applications

The ZH127 Series connector is widely applied in various low-frequency electronic and electrical systems, including:

-- Industrial electronic equipment

-- Control systems

-- Communication equipment

-- Electrical measurement devices

-- Automation systems

-- Power control units

-- Equipment wiring systems

-- Custom cable assemblies

Technical Specifications

Product Advantages

-- Reliable connection performance for long-term operation

-- Quick bayonet coupling reduces installation time

-- Multiple key positions prevent incorrect assembly

-- High insulation resistance improves electrical safety

-- Durable aluminum alloy shell extends service life

-- Flexible compatibility with various replacement connector series

-- Suitable for equipment upgrades and maintenance projects

-- Supports customized cable solutions according to customer requirements

Manufacturing Process

ZH127 connectors are manufactured through precision metal machining, contact plating, insulation molding, component assembly, solder connection inspection, and electrical performance testing. Strict quality control is applied throughout the production process to ensure accurate dimensions, stable contact performance, and consistent reliability for every connector supplied.

Our Service

-- OEM and ODM customization support

-- Customized cable assembly solutions

-- Connector selection assistance

-- Sample orders available

-- Professional technical support

-- Flexible production quantities

-- Export-standard packaging and delivery service

Frequently Asked Questions

Q1. What applications are suitable for the ZH127 Series connector?
The ZH127 Series is suitable for low-frequency electronic systems, industrial equipment, control systems, and electrical devices requiring reliable signal and power connections.

Q2. Is the ZH127 connector compatible with other connector models?
Yes. It is interchangeable and intermateable with compatible OHS-BC, ONTs-BS, SNTs127, and SNC127 connector series.

Q3. What is the benefit of the bayonet connection design?
The bayonet coupling provides fast installation and secure locking, helping maintain stable performance under vibration and repeated operation.

Q4. Can you provide customized connectors or cable assemblies?
Yes. We provide OEM/ODM services, including customized structures, cable assemblies, markings, and packaging solutions.
