SF6 Load Breaker
SF6 Load Breaker
Specifications
Item :
Rated short-time withstand current(4s)
No. :
1
Unit :
A
Data :
20
Description

LW34-12/24 SF6 Load Break Switch

The LW34-12/24 SF6 Load Break Switch is engineered for high-performance outdoor 12kV or 24kV three-phase AC 50/60Hz power systems. Designed to reliably open and close load currents and short-circuit currents, this switch ensures stability in demanding electrical environments.

Key Advantages

  • ✅ Superior Durability: Stainless steel panel offers excellent antisepsis and sealing performance.
  • ✅ Maintenance-Free: Engineered for long-term operational reliability without requiring frequent servicing.
  • ✅ Safety First: Equipped with an integrated anti-explode device.
  • ✅ Operational Efficiency: Lightweight design for easy transit and automatic locking at 0.03 to 0.07MPa pressure.

Product Attributes

Application: Outdoor Power Systems
Material: Stainless Steel Panel
Frequency: 50/60Hz

Technical Specifications

Item Unit Data
Rated voltagekV12/24
Rated currentA630
Rated SF6 pressureMpa0.12
Rated short-time withstand current (4s)kA20
Rated peak withstand currentkA50
Rated SF6 yearly gas leakage rate-≤1%
