Steel Structure Pre Manufactured Pedestrian Bridges / Prefabricated Truss Bridge
Steel Structure Pre Manufactured Pedestrian Bridges / Prefabricated Truss Bridge
Specifications
Brand Name :
Zhonghai Bailey Bridge
Model Number :
CB200/CB321
Certification :
IS09001, CE
Place of Origin :
China
MOQ :
1 Pcs
Price :
USD 95-450
Payment Terms :
L/C,D/P,T/T
Supply Ability :
60000ton/year
Delivery Time :
8-10 work days
Packaging Details :
Naked
Product Capability :
60000 Pieces Per Year
Standard :
ASTM,GB,BS,BV
Structure Type :
Truss bridge
Modular Design :
Yes
Weather Resistance :
High
Maintenance Requirements :
Low
Surface Finishing :
Galvanized finish
Name :
Bailey Bridge
Grade :
Q355B
Description

Steel Structure Bridge Manufacture/steel Structure Bridges Supplier


Inspecting Bailey bridges for algae growth should be conducted regularly to prevent potential issues. Based on maintenance guidelines and practices, it is recommended to inspect for algae growth at least twice a year. This frequency can be adjusted depending on the specific environmental conditions:


1. **Humid or Coastal Areas**:

In regions with high humidity or proximity to water bodies, where algae growth is more likely, inspections should be conducted more frequently, potentially every three to four months.


2. **Routine Cleaning and Inspection**:

During routine maintenance, which includes cleaning the bridge deck, substructure, and steel surfaces, it is important to check for signs of algae or moss. This helps in early detection and removal.


3. **Environmental Considerations**:

If the bridge is located in an area with significant environmental concerns, such as near sensitive habitats or water bodies, more frequent inspections may be necessary to comply with environmental regulations.

By following these inspection frequencies, you can effectively manage algae growth and ensure the longevity and safety of the bridge.




Specifications:

​

CB200 Truss Press Limited Table
NO. Internal Force Structure Form
Not Reinforced Model Reinforced Model
SS DS TS QS SSR DSR TSR QSR
200 Standard Truss Moment(kN.m) 1034.3 2027.2 2978.8 3930.3 2165.4 4244.2 6236.4 8228.6
200 Standard Truss Shear (kN) 222.1 435.3 639.6 843.9 222.1 435.3 639.6 843.9
201 High Bending Truss Moment(kN.m) 1593.2 3122.8 4585.5 6054.3 3335.8 6538.2 9607.1 12676.1
202 High Bending Truss Shear(kN) 348 696 1044 1392 348 696 1044 1392
203 Shear Force of Super High Shear Truss(kN) 509.8 999.2 1468.2 1937.2 509.8 999.2 1468.2 1937.2
Steel Structure Pre Manufactured Pedestrian Bridges / Prefabricated Truss BridgeSteel Structure Pre Manufactured Pedestrian Bridges / Prefabricated Truss BridgeSteel Structure Pre Manufactured Pedestrian Bridges / Prefabricated Truss BridgeSteel Structure Pre Manufactured Pedestrian Bridges / Prefabricated Truss Bridge

​​

CB200 Table of Geometric Characteristics of Truss Bridge(Half Bridge)
Structure Geometric Characteristics
Geometric Characteristics Chord Area(cm2) Section Properties(cm3) Moment of Inertia(cm4)
ss SS 25.48 5437 580174
SSR 50.96 10875 1160348
DS DS 50.96 10875 1160348
DSR1 76.44 16312 1740522
DSR2 101.92 21750 2320696
TS TS 76.44 16312 1740522
TSR2 127.4 27185 2900870
TSR3 152.88 32625 3481044
QS QS 101.92 21750 2320696
QSR3 178.36 38059 4061218
QSR4 203.84 43500 4641392
Steel Structure Pre Manufactured Pedestrian Bridges / Prefabricated Truss BridgeSteel Structure Pre Manufactured Pedestrian Bridges / Prefabricated Truss BridgeSteel Structure Pre Manufactured Pedestrian Bridges / Prefabricated Truss BridgeSteel Structure Pre Manufactured Pedestrian Bridges / Prefabricated Truss Bridge

​​

CB321(100) Truss Press Limited Table
No. Lnternal Force Structure Form
Not Reinforced Model Reinforced Model
SS DS TS DDR SSR DSR TSR DDR
321(100) Standard Truss Moment(kN.m) 788.2 1576.4 2246.4 3265.4 1687.5 3375 4809.4 6750
321(100) Standard Truss Shear (kN) 245.2 490.5 698.9 490.5 245.2 490.5 698.9 490.5
321 (100) Table of geometric characteristics of truss bridge(Half bridge)
Type No. Geometric Characteristics Structure Form
Not Reinforced Model Reinforced Model
SS DS TS DDR SSR DSR TSR DDR
321(100) Section properties(cm3) 3578.5 7157.1 10735.6 14817.9 7699.1 15398.3 23097.4 30641.7
321(100) Moment of inertia(cm4) 250497.2 500994.4 751491.6 2148588.8 577434.4 1154868.8 1732303.2 4596255.2
Steel Structure Pre Manufactured Pedestrian Bridges / Prefabricated Truss BridgeSteel Structure Pre Manufactured Pedestrian Bridges / Prefabricated Truss BridgeSteel Structure Pre Manufactured Pedestrian Bridges / Prefabricated Truss BridgeSteel Structure Pre Manufactured Pedestrian Bridges / Prefabricated Truss Bridge

​


Advantage

Possessing the features of simple structure,
convenient transport, speedy erection
easy disassembling,
heavy loading capacity,
great stability and long fatigue life
being capable of an alternative span, loading capacity


Steel Structure Pre Manufactured Pedestrian Bridges / Prefabricated Truss Bridge
