Safety Temporary Bailey Bridge For Sale Steel Structure Withstand Heavy Loads And Harsh Environments
Safety Temporary Bailey Bridge For Sale Steel Structure Withstand Heavy Loads And Harsh Environments
Specifications
Brand Name :
Zhonghai Bailey Bridge
Model Number :
CB200/CB321
Certification :
IS09001, CE
Place of Origin :
China
MOQ :
1 Pcs
Price :
USD 95-450
Payment Terms :
L/C,D/P,T/T
Supply Ability :
60000ton/year
Delivery Time :
8-10 work days
Packaging Details :
Naked
Dimensions :
Standard or Customized
Name :
Bailey Bridge
Standard :
ASTM,GB,BS,BV
Secondary Steel :
Q235
Application :
Steel Structure Bridge
Corrosion Resistance :
Galvanized or painted finish
Safety Features :
Designed to withstand heavy loads and harsh environments
Main Steel :
GB Q345B
Product Capability :
60000 Pieces Per Year
Grade :
Q355B
Description

Temporary Bridge Bailey Bridge For Sale/certificated Bailey Bridge


Midas Civil also streamlines the design process by providing automatic code checking and generating comprehensive reports. This capability significantly reduces the time spent on documentation and improves communication with clients and stakeholders.

Moreover, the integration of BIM (Building Information Modeling) features in Midas Civil fosters collaboration among project teams, allowing for seamless data sharing and coordination. Ultimately, using Midas Civil for Bailey Bridge calculations enhances the overall design process, ensuring efficient, safe, and high-quality bridge engineering.



Specifications:

​

CB321(100) Truss Press Limited Table
No. Lnternal Force Structure Form
Not Reinforced Model Reinforced Model
SS DS TS DDR SSR DSR TSR DDR
321(100) Standard Truss Moment(kN.m) 788.2 1576.4 2246.4 3265.4 1687.5 3375 4809.4 6750
321(100) Standard Truss Shear (kN) 245.2 490.5 698.9 490.5 245.2 490.5 698.9 490.5
321 (100) Table of geometric characteristics of truss bridge(Half bridge)
Type No. Geometric Characteristics Structure Form
Not Reinforced Model Reinforced Model
SS DS TS DDR SSR DSR TSR DDR
321(100) Section properties(cm3) 3578.5 7157.1 10735.6 14817.9 7699.1 15398.3 23097.4 30641.7
321(100) Moment of inertia(cm4) 250497.2 500994.4 751491.6 2148588.8 577434.4 1154868.8 1732303.2 4596255.2
Safety Temporary Bailey Bridge For Sale Steel Structure Withstand Heavy Loads And Harsh EnvironmentsSafety Temporary Bailey Bridge For Sale Steel Structure Withstand Heavy Loads And Harsh EnvironmentsSafety Temporary Bailey Bridge For Sale Steel Structure Withstand Heavy Loads And Harsh EnvironmentsSafety Temporary Bailey Bridge For Sale Steel Structure Withstand Heavy Loads And Harsh Environments

​​

CB200 Truss Press Limited Table
NO. Internal Force Structure Form
Not Reinforced Model Reinforced Model
SS DS TS QS SSR DSR TSR QSR
200 Standard Truss Moment(kN.m) 1034.3 2027.2 2978.8 3930.3 2165.4 4244.2 6236.4 8228.6
200 Standard Truss Shear (kN) 222.1 435.3 639.6 843.9 222.1 435.3 639.6 843.9
201 High Bending Truss Moment(kN.m) 1593.2 3122.8 4585.5 6054.3 3335.8 6538.2 9607.1 12676.1
202 High Bending Truss Shear(kN) 348 696 1044 1392 348 696 1044 1392
203 Shear Force of Super High Shear Truss(kN) 509.8 999.2 1468.2 1937.2 509.8 999.2 1468.2 1937.2
Safety Temporary Bailey Bridge For Sale Steel Structure Withstand Heavy Loads And Harsh EnvironmentsSafety Temporary Bailey Bridge For Sale Steel Structure Withstand Heavy Loads And Harsh EnvironmentsSafety Temporary Bailey Bridge For Sale Steel Structure Withstand Heavy Loads And Harsh EnvironmentsSafety Temporary Bailey Bridge For Sale Steel Structure Withstand Heavy Loads And Harsh Environments

​​

CB200 Table of Geometric Characteristics of Truss Bridge(Half Bridge)
Structure Geometric Characteristics
Geometric Characteristics Chord Area(cm2) Section Properties(cm3) Moment of Inertia(cm4)
ss SS 25.48 5437 580174
SSR 50.96 10875 1160348
DS DS 50.96 10875 1160348
DSR1 76.44 16312 1740522
DSR2 101.92 21750 2320696
TS TS 76.44 16312 1740522
TSR2 127.4 27185 2900870
TSR3 152.88 32625 3481044
QS QS 101.92 21750 2320696
QSR3 178.36 38059 4061218
QSR4 203.84 43500 4641392
Safety Temporary Bailey Bridge For Sale Steel Structure Withstand Heavy Loads And Harsh EnvironmentsSafety Temporary Bailey Bridge For Sale Steel Structure Withstand Heavy Loads And Harsh EnvironmentsSafety Temporary Bailey Bridge For Sale Steel Structure Withstand Heavy Loads And Harsh EnvironmentsSafety Temporary Bailey Bridge For Sale Steel Structure Withstand Heavy Loads And Harsh Environments

​


Advantage

Possessing the features of simple structure,
convenient transport, speedy erection
easy disassembling,
heavy loading capacity,
great stability and long fatigue life
being capable of an alternative span, loading capacity


Safety Temporary Bailey Bridge For Sale Steel Structure Withstand Heavy Loads And Harsh Environments
