Home Using Mesh Wifi Router / Wireless Mesh Router Dual Band Openwrt System
Home Using Mesh Wifi Router / Wireless Mesh Router Dual Band Openwrt System
Home Using Mesh Wifi Router / Wireless Mesh Router Dual Band Openwrt System
Home Using Mesh Wifi Router / Wireless Mesh Router Dual Band Openwrt System
Specifications
Brand Name :
OEM
Model Number :
Mesh-L1
Certification :
FCC,CE,ROSH
Place of Origin :
China
MOQ :
2 pieces
Price :
$22-24/pcs
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100000pieces/month
Delivery Time :
Sample order:7-10days;batch order 30days
Packaging Details :
paper box
Color :
White
Main Chipset :
RTL8197FNT-VE4-CG
Antenna :
2* Internal 3dBi Omnidirectional dual frequency antenna
wireless rate: :
1200Mbps
Max. LAN Data Rate: :
100Mbps
Interface :
1WAN+1LAN
Type :
Wireless
Function :
Firewall, QoS, VPN
Description

Mesh Wifi Router Wireless Network Dual Band Openwrt For Home Using

1,Simple Introduction

MESH Routing System ZBT-L1 is a dual-band home wireless networking suite. Each node has a 10/100Mbps WAN/LAN adaptive port, a 10/100Mbps adaptive LAN port, and a wireless transmission rate of 1167Mbps.

2,Specification

Type Demand item Specification
Wire Interface WAN Port 1*10/100 Base-T Interface,IEEE802.3/802.3u Protocol, Support full-duplex / half-duplex flow control.
LAN Port 1*10/100 Base-T Interface,IEEE802.3/802.3u Protocol,Support full-duplex / half-duplex flow control.
Adapter

1*DC Port,the router is powered by an external power adapter. External power adapter should:

1. Meet the EMC requirements of YD/T 983 and pass CCC certification;

2. Input voltage: 198V-242V ~ 50Hz;

3. Output voltage DC: 9V ± 5%, ripple range ± 100mV, output current: 1A;

4. The MTBF time of the power supply is: greater than 30,000 hours;

5. The power interface of the device itself and the DC output interface of the power adapter should be a unified international standard circular interface, and the DC head diameter is 2.1mm;

6. The adapter's DC output power cord can be optionally equipped with an EMI absorption magnetic ring;

7. Under normal conditions, the insulation resistance between the metal casing of the equipment and the power line should be not less than 50MΩ.

8, should have lightning protection against surge test, lightning protection level of at least 1.5KV.
Wireless Port Wi-Fi Networking

802.11b/g/n/a/ac;2.4GHz/5GHz,Wireless Rate 1167Mbps.

2* Internal 3dBi Omnidirectional dual frequency antenna.

The Current wifi Device quantity can highly reach to 32
