Specifications
Brand Name :
YZY
Model Number :
E110XD-W-C10-01
Place of Origin :
Guangdong, China
MOQ :
500 pieces
Price :
$2.6/pieces 100-499 pieces
Payment Terms :
T/T
Supply Ability :
10000Pieces
Delivery Time :
14-30 days
Packaging Details :
8*8*4
Certification :
CE, ROHS
Description



This product is the 1.1-inch OLED display module model E110XD-W-C10-01, equipped with a high-performance SH1107 driver IC and advanced COG (Chip on Glass) packaging technology. It not only features a compact structure but also achieves stable and reliable drive control, significantly reducing the risk of integration failures. With a 96×96 high-definition resolution, paired with a fine pixel pitch of 0.205mm, a tiny pixel size of 0.18mm, and a 19.655×19.655mm golden-ratio active display area, it delivers a delicate and sharp white display effect with extremely high text and pattern restoration. Adopting an industry-universal 4-Wire SPI interface design, it boasts strong compatibility, allowing quick connection to various electronic devices without complex debugging, thus greatly improving R&D and production efficiency.

With an ultra-slim and compact size of 25.49 (W) × 29.1 (H) × 1.45 (T) mm, the module can be easily adapted to space-constrained scenarios such as smart wearables, portable devices, and industrial controllers, providing more flexibility for product structure design. It possesses exceptional environmental adaptability, with a wide operating temperature range of -20℃~70℃ and a storage temperature range of -30℃~80℃. It can smoothly cope with harsh environments such as low outdoor temperatures and high industrial temperatures without the need for additional temperature control devices. Meanwhile, the product strictly complies with the EU RoHS environmental standards, with no release of harmful substances, meeting global environmental compliance requirements and can be safely used in various export and domestic products.


The optical performance is outstanding: the typical brightness reaches 100cd/m², combined with an ultra-high contrast ratio of 10000:1, resulting in clear black-and-white boundaries and distinguishable display details in darkroom environments. The ultra-fast response time of 0.02ms (rise + decay) completely eliminates motion blur, ensuring smoother dynamic display. It supports 160° full-view viewing, maintaining consistent color and brightness from any angle without the need to align the screen intentionally. The product has passed rigorous reliability tests, with a MTBF (Mean Time Between Failures) of no less than 50,000 hours and a service life of up to 20,000 hours under normal use. Verified through multiple tests such as high-low temperature cycling and damp-heat storage, it operates stably without attenuation for a long time, reducing later maintenance costs.
