1800KN Load Drilling Top Drive 45 KNm Torque Top Drive Unit VFD Controlled
1800KN Load Drilling Top Drive 45 KNm Torque Top Drive Unit VFD Controlled
Specifications
Delivery Time :
15-30 working days
Model Number :
200T
MOQ :
1 pcs
Rated Continuous Output Torque :
30 KN·m
Maximum Make‑and‑Break Torque :
45 KN·m
Drive Mode :
AC Variable Frequency Motor
Brand Name :
XI'AN RIG
Place of Origin :
China
Payment Terms :
L/C, T/T
Model :
200T
Rated Load :
1800 KN
Brake Braking Torque :
30 KN·m
Certification :
API
Description

200T Variable Frequency Drive Top Drive for Land Drilling Rigs

1800KN Load Drilling Top Drive 45 KNm Torque Top Drive Unit VFD Controlled

Specifications:

1 Nominal Drilling Depth Range 2000 m
2 Drive Mode Direct‑driven by AC variable‑frequency motor
3 Rated Load (Elevator, Main Shaft) 1800 KN
4 Rated Continuous Output Torque 30 KN·m
5 Maximum Make‑and‑Break Torque 45 KN·m
6 Brake Braking Torque 30 KN·m
7 Main Shaft Rotation Speed (Stepless Adjustable) 0～180 r/min
8 Back Tong Drill Pipe Clamping Range 2 7/8"～4 1/2"
9 Hydraulic System Working Pressure 0～16 MPa
10 Rated Pressure of Mud Circulation Passage 35 MPa
11 Mud Passage Bore Diameter 60 mm
12 IBOP Rated Pressure 70 MPa
13 Protector Connection Type NC38～NC50
14 Power Supply for Electric Control House 600 VAC / 50Hz
15 Working Voltage of Explosion‑proof Solenoid Valve 24 VDC
16 Overall Dimension of Top Drive 4400 mm×1220 mm×1100 mm
17 Working Height 4.8 m
18 Main Body Weight 6.5 T
19 Applicable Ambient Temperature -45℃～55℃
