WNK Low Cost Water Pressure Sensor Transmitter for Pressure Measuring Instruments
WNK Low Cost Water Pressure Sensor Transmitter for Pressure Measuring Instruments
WNK Low Cost Water Pressure Sensor Transmitter for Pressure Measuring Instruments
WNK Low Cost Water Pressure Sensor Transmitter for Pressure Measuring Instruments
WNK Low Cost Water Pressure Sensor Transmitter for Pressure Measuring Instruments
WNK Low Cost Water Pressure Sensor Transmitter for Pressure Measuring Instruments
Specifications
Brand Name :
WNK
Model Number :
WNK80ma
Certification :
CE/ROHS
Place of Origin :
Chian
Measured media :
Water, Air, Gas, Steam
Housing material :
304SS, 316SS
Accuracy :
0.5%FS
Pressure range :
10kpa, -100kpa...70Mpa
Applications :
Water Air Refrigerant HVAC, Automobile
Output signal :
4-20mA, 0.5-4.5V, 0--10V, 3.3V, I2C, RS485
Pressure Type :
Gauge Pressure, Absolute Pressure, Sealing Pressure
IP rating :
IP65
Description

WNK 4-20ma 0.5-4.5V I2C Water Pressure Sensor for Air Oil Gas

Product Description
Applicable media
Liquid, Gas
Pressure Range
0-60bar/-1-700Bar
Pressure Type
Gauge Pressure, Absolute pressure, Sealing pressure
Output
4-20mA/0.5-4.5V/1 -5V/0-10V/I2C
Accuracy(linearity,Hysteresis and Repeatability)
0.5%F.S./1%FS (Typical)
0.5%F.S.(Typical)
24VDC/12VDC/5VDC/3.3V
Compensation temperature
-20~85ºC
Ambient temperature
-40~125ºC
Working temperature
-40~125ºC
Temperature drift(zero)
±0.15% F.S. (-20~85ºC)
Temperature drift(full range)
±0.15% F.S. (-20~85ºC)
power(electrical) connect
Parkard, M12, DIN43650, Cable outlet
Mechanical connection
G1/4, 1/4NPT, 1/8NPT, M12*1.5, customize
Housing material
304 stainless steel(inner core is 316 stainless steel)
Protection
IP65

WNK81MA is silicon oil filled pressure transducer, using imported ASCI signal conditioning chip and diffused silicon oil filled sensor core.It has features of anti-corrosion, anti-wear, shock resistance and vibration resistance. With long-term stability and high accuracy, it widely used in the pressure measurement and control fields of HVAC, Auto, Pumping, water treatment and etc.With certification of UL, RoHs, Reach, CE, UKCA, WNK81mA will quickly help you expand your market.

Applications


-Automobile, Compressor and Refrigeration Industry-Engineering machinery
-Pressure control and monitor
-Water treatment system
-Hydraulic and Pneumatics
-HAVC and BAS Control
-Pump, fitness equipment,household appliances
-Factory Automation
-Fluid Control and Instrumentation Systems
Electrical Connection
