Q235 Heavy Duty Ringlock Scaffolding System Professional Modular Scaffolding
Q235 Heavy Duty Ringlock Scaffolding System Professional Modular Scaffolding
Specifications
Certification :
ROHS
Material :
Q235
Price :
US $10.00 - 11.40/ Piece
Packaging Details :
Bundled / Tied in bundles/Optimization of container loading
Surface Treatment :
Powder Coated/Hot Dip Galvanizing
Color :
Silver
Supply Ability :
1000 piece in 10 days
Length :
200mm/250mm/300mm/350mm/500mm/1000mm/1500mm/2000mm/2500mm/3000mm
MOQ :
200/Piece
Pipe Wall Thickness :
3.0mm/3.2mm/3.25mm or customized
Scaffolding Part Type :
Cuplock Scaffolding Accessories
Payment Terms :
T/T
Weight :
1.8KG-18.75KG according to different sizes
Delivery Time :
10-30 workday
Design Style :
Morden
Corrosionresistance :
Galvanized coating
Place of Origin :
Hebei,China
Diameter :
60mm&48mm
Brand Name :
WKS
Product name :
Ring Lock Scaffold
Description
Heavy Duty Ringlock Scaffolding System | Professional Modular Scaffolding Manufacturer
Product Overview

Our Ringlock Scaffolding System is a world-class modular scaffolding solution designed for maximum safety, durability, and assembly speed. Widely used in large-scale construction, infrastructure, and real estate projects, this system features a unique 8-hole rosette connection, allowing for versatile angles and complex structures.

As a leading scaffolding manufacturer, we ensure our products meet the highest international standards, providing a 20-year service life for your engineering needs.

Key Advantages
  • Superior Load Capacity: Engineered with high-strength Q345B steel, a single standard can bear up to 20 tons, ensuring safety for heavy-duty projects.
  • Enhanced Durability: All components are Hot-Dip Galvanized (HDG) with a zinc coating >80μm, providing excellent corrosion resistance even in coastal or industrial environments.
  • Cost-Efficient Assembly: The modular wedge-lock mechanism increases installation efficiency by 300% compared to traditional tube and clamp scaffolding.
  • Global Standard Compliance: Fully compliant with EN 12810, BS 1139, and AS/NZS 1576 standards, making it the preferred choice for international contractors.
Technical Specifications
Parameter Details
Product Name Ringlock Scaffolding / Rosette Scaffolding
Material Grade Q345B (Standards), Q235 (Ledgers & Braces)
Surface Treatment Hot-Dip Galvanized (HDG) / Painted / Electro-galvanized
Tube Diameter 48.3mm / 60mm
Tube Thickness 3.2mm / 3.25mm / 4.0mm
Rosette Spacing 500mm (Standard)
Key Components Vertical Standard, Horizontal Ledger, Diagonal Brace, Base Jack
Service Life 15 - 20 Years
Why Choose Our Ring Lock Scaffold?
  • Safety First: Precision welding and automated production lines ensure zero-defect components.
  • Factory Direct Price: Eliminate middleman costs and get the most competitive quote for bulk orders.
  • Technical Support: We provide 3D layout design and loading capacity calculations for your specific projects.
Q235 Heavy Duty Ringlock Scaffolding System Professional Modular Scaffolding
Contact Us for a Fast Quote

Are you looking for a reliable Ringlock Scaffolding supplier for your next project?

Inquiry Now

Get our latest product catalog and technical brochure.
