4.2m/S GP15 Torsion Spring Rolling Ring Traverse Drive
4.2m/S GP15 Torsion Spring Rolling Ring Traverse Drive
4.2m/S GP15 Torsion Spring Rolling Ring Traverse Drive
4.2m/S GP15 Torsion Spring Rolling Ring Traverse Drive
4.2m/S GP15 Torsion Spring Rolling Ring Traverse Drive
4.2m/S GP15 Torsion Spring Rolling Ring Traverse Drive
4.2m/S GP15 Torsion Spring Rolling Ring Traverse Drive
4.2m/S GP15 Torsion Spring Rolling Ring Traverse Drive
4.2m/S GP15 Torsion Spring Rolling Ring Traverse Drive
4.2m/S GP15 Torsion Spring Rolling Ring Traverse Drive
4.2m/S GP15 Torsion Spring Rolling Ring Traverse Drive
4.2m/S GP15 Torsion Spring Rolling Ring Traverse Drive
Specifications
Brand Name :
QIPANG
Model Number :
GP3-15
Certification :
CE
Place of Origin :
Shanxi, China
MOQ :
1
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3000 units per month
Delivery Time :
10 working days
Packaging Details :
Wooden box
Name :
GP3-15 C type Rolling Ring Traverse Drive With Support Bracket
Other name :
Rolling Ring Traverse Drive
Keywords :
rolling ring drive
Model :
GP3-15
Type :
C type
Brand :
XINDIAN
Origin :
Shanxi, China
Warranty :
1 year
Weight :
7kg
Description

GP3-15 Variable Traversing Speed GP15 Rolling Ring Traverse Drive With Torsion Spring China Factory Direct

Principle

The principle of operation of the rolling ring drive is that, based on the transformation of the rotational movement of the drive shaft into a linear movement, the rolling ring drive moves on a smooth shaft in two directions, using the interaction of friction forces between the drive shaft and the collars of the ball bearing mechanism for switching the stroke of the rolling ring drive.

The main advantages of the rolling ring xindian drive principle

1.Highest possible efficiency due to the fact that the gear and the payload are completely supported by roller bearings

2.Automatic traversing movement

3.Variable traversing speeds ranging from 0 m/s to a maximum of 4.2 m/s; can also be separately set for the two directions with constant rotation of the shaft

4.Variable traversing width and traversing position

5.High dynamics at the points of reversal

6.Can be released from the shaft

7.Low operating costs

8.Low maintenance requirements

4.2m/S GP15 Torsion Spring Rolling Ring Traverse Drive

4.2m/S GP15 Torsion Spring Rolling Ring Traverse Drive

1 - folding carriage; 2 - roller bracket; 3 - vertical roller; 4 - horizontal roller; 5 - smooth shaft; 6 - support bracket; 7 - guide rail; 8 - hairpin; 9 - restrictive nut carriage stroke; 10 - bolt for adjusting the distance of m/s rollers; 11 - keyway under the pulley

Parameters of linear traverse units
Model
d1
d2*
L1*
L2
L3
L4
L5
L6
Md
GP3-15
15
15
430
13
72
-
47
-
M8
GP3-20
20
14
450
14
102
40
41
25
