Specifications
Brand Name :
QIPANG
Model Number :
GP3-40
Certification :
CE
Place of Origin :
Shanxi, China
MOQ :
1
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3000 units per month
Delivery Time :
10 working days
Packaging Details :
Wooden box
Name :
GP3-40 B type Rolling Ring Traverse Drive With Guiding Rollers
Other name :
Rolling Ring Traverse Drive
Keywords :
rolling ring drive
Model :
GP3-40
Type :
B type
Brand :
XINDIAN
Origin :
Shanxi, China
Warranty :
1 year
Weight :
7kg
Description

GP3-40 B Type Ring Bearing Rolling Ring Traverse Drive Wire Guiding Roller For Wire Winding Machine China Factory Direct

The main advantages of the rolling ring xindian drive principle

1.Highest possible efficiency due to the fact that the gear and the payload are completely supported by roller bearings

2.Automatic traversing movement

3.Variable traversing speeds ranging from 0 m/s to a maximum of 4.2m/s; can also be separately set for the two directions with constant rotation of the shaft

4.Variable traversing width and traversing position

5.High dynamics at the points of reversal

6.Can be released from the shaft

7.Low operating costs

8.Low maintenance requirements

11mm Pitch 4.2m/S Wire Winding B Type Ring Traverse Drive

11mm Pitch 4.2m/S Wire Winding B Type Ring Traverse Drive

1 - folding carriage; 2 - roller bracket; 3 - vertical roller; 4 - horizontal roller; 5 - smooth shaft; 6 - support bracket; 7 - guide rail; 8 - hairpin; 9 - restrictive nut carriage stroke; 10 - bolt for adjusting the distance of m/s rollers; 11 - keyway under the pulley

Parameters of linear traverse units
Model
d1
d2*
L1*
L2
L3
L4
L5
L6
Md
GP3-15
15
15
430
13
72
-
47
-
M8
GP3-20
20
14
450
14
102
40
41
25
