Specifications
Wire Diameter :
0.5mm
Usage :
Absorbing Shock
Warranty :
1 Year
Place of Origin :
Shaanxi, China
Product Load Capacity :
Customizable
Model Number :
JZP-1.0C
Maintenance :
Low
Payment Terms :
L/C,D/A,D/P,T/T
Mounting Thread Size :
M5
MOQ :
4 Pieces
Delivery Time :
7 working days for stock orders
Feature :
Vibration isolation
Brand Name :
Hoan
Certification :
ISO9001:2015
Description

JZP-1.0C Rubber Shock Absorber with Self-Healing Elastomer Chemistry


The JZP-1.0C is a prefabricated rubber shock absorber built for continuous vibration and noise isolation in industrial, railway and precision-equipment installations. With a 1.0 kg nominal load rating and a low-maintenance design, it suits service points where damping behaviour must stay stable across long operating intervals.


How Self-Healing Elastomer Chemistry Works


Under repeated dynamic loading, ordinary elastomers collect micro-cracks that slowly reduce damping ability. The JZP-1.0C counters this with self-healing elastomer chemistry. Reversible dynamic bonds inside the rubber network re-associate after localised stress, allowing micro-cracks to close on their own between load cycles. Rather than drifting out of specification, the mount holds its isolation behaviour as duty cycles accumulate.


Dynamic Self-Healing Rubber Matrix


The dynamic self-healing rubber matrix spreads stress evenly through the vulcanised body. Because the matrix keeps repairing itself under cyclic compression and shear, the absorber retains a stable resonant frequency of 35±3 Hz with high internal damping throughout its working life. This means fewer re-torquing tasks, fewer replacements and less downtime at mounting points that are hard to reach.


Technical Parameters (JZP-1.0C)


Model JZP-1.0C
Pz Nominal Load (Kg) 1.0
Deformation Displacement (mm) ≤0.3
Resonant Frequency (Hz) 35±3
Working Temperature (℃) -45 to +65
Shock (Ks) 100g/6ms
Peak Response (G) ≤3.6km/s2
Vibration (Kv) Accord with National Standard GJB150-16
Mounting Thread M5 threaded hole


JZP-C Series Load Reference


Technical Parameter JZP-0.3C JZP-0.5C JZP-0.8C JZP-1.0C JZP-1.2C JZP-1.5C JZP-1.8C JZP-2.0C JZP-2.5C JZP-3.0C
Pz Nominal Load (Kg) 0.3 0.5 0.8 1.0 1.2 1.5 1.8 2.0 2.5 3.0



Typical Applications


  • Rail vehicle suspension and track-bed isolation.
  • Industrial machinery, pumps and enclosure vibration control.
  • Precision instruments that react to low-amplitude vibration.
  • Building and bridge structures exposed to low-frequency noise.
  • Energy and mining equipment running around the clock.
