Specifications
Brand Name :
TX TELSIG
Model Number :
TX-CZ10W
Certification :
SGS，ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T,Paypal,L/C,D/A,D/P,Etc.
Supply Ability :
5000pcs/per month
Delivery Time :
2 work days
Packaging Details :
Durable Case or Customized
Frequency :
Customized
Test voltage :
24/28/32V
Current :
2.4A
Output :
20W
Gain :
43dB
Connector :
SMA / Female
Output connector VSWR :
≤1.30 (No power and VNA test)
Power supply wire :
Red+Black wire
Advantage :
Circulator designed
Out shell Size :
119*39*16mm
Mount hole :
35*151mm
Weight :
151g
Work Temperature :
-40~+65℃
Out shell material :
Aluminum
Vibration need :
Car load OK
Description

300-2700MHz 20W Jammer module with Circulator

This module is 20W output with circulator jammer module .The jammer module is good in-band flatness and the small offset between upper and lower side band.

The frequency band and output power of the module can be customized according to customer needs.

Parameter

No. Item Data Unit
1 Frequency Customized MHz
2 Test voltage 24-28 V
3 Current 2.4 A
4 Output 20 W
5 Gain 43 dB
6 Connector SMA / Female
7 Output connector VSWR ≤1.30 (No power and VNA test)
8 Power supply wire Red+Black wire
9 Advantage Circulator designed
10 Out shell Size 119*39*16mm mm
11 Mount hole 35*151 mm
12 Weight 151 g
13 Work Temperature -40~+65 ℃
14 Out shell material Aluminum
15 Vibration need Car load OK

Long-Range Drone Signal Blocker UAV Jamming Module 20 Watt Output Anti-Drone RF Module

Attention

• Power supply better carry about 28V 3.6A when itself 2.4A for its stable work

• Heat dissipation measure is necessary including the thermal glue, suitable-size heat sink and cooling fans

• Antenna or Load must be firstly connected before the power supply is ON or it will be short wire
