ST303C12CFK0 1200V 300A Half-Bridge Module Low Vce(sat) Low Loss Short Circuit Ruggedness Integrated NTC For Motor Drives and Industrial Inverters
Features

  • Half-Bridge IGBT Module

  • Power Rating: 1200V / 300A

  • Low Vce(sat) (Low Conduction Losses)

  • Optimized Switching Losses

  • High Short-Circuit Ruggedness (SCWT)

  • Integrated NTC Temperature Sensor

  • Low-Inductance Design

  • Industrial Grade Robustness

Applications

  • Industrial Motor Drives: For pumps, fans, compressors, and conveyor systems.

  • General-Purpose Industrial Inverters and Frequency Converters.

  • Uninterruptible Power Supplies (UPS): Three-phase systems.

  • Welding Equipment Power Supplies.

Description
The ST303C12CFK0 is a robust half-bridge IGBT module designed for high-performance industrial motor drives and power conversion applications. It features a 1200V blocking voltage and a 300A current rating, delivering reliable power for medium to high-power systems. The module utilizes advanced IGBT and freewheeling diode technology to achieve a low collector-emitter saturation voltage (Vce(sat)) for high efficiency during conduction and optimized switching characteristics to manage losses. It is engineered for industrial ruggedness, offering a high level of short-circuit withstand capability and integrating a negative temperature coefficient (NTC) thermistor for precise temperature monitoring, ensuring system protection and reliability.
Technical Specifications
category
Discrete semiconductor products
thyristors
SCR
manufacturer
Vishay General Semiconductor - Diodes Division
series
-
Packaging
Bulk
Part status
Discontinued
Voltage - Fault state
1.2 kV
Voltage - Gate Trigger (Vgt) (Max)
3 V
Current - Gate Trigger (IGT) (Max)
200 mA
Voltage - On-State (Vtm) (Max)
2.16 V
Current - On-State (It (AV)) (Max)
620 A
Current - Normal State (It (RMS)) (Max)
1180 A
Current - Hold (Ih) (max)
600 mA
Current - Fault State (Max)
50 mA
Current - Non-repeating surge 50, 60Hz (Itsm)
7950A,8320A
SCR type
Standard recovery
Operating temperature
-40°C ~ 125°C
Mounting type
Clamp style
Package/Enclosure
TO-200AB,E-PUK
Vendor device packages
TO-200AB(E-Puk)
Base product number
ST303
Drawing
