Description
VS-ST330C16C0 1600V 330A Half-Bridge Module Low Vce(sat) Low Loss High Short Circuit Ruggedness Integrated NTC For Industrial Inverters and High Power UPS
Features

  • Half-Bridge IGBT Module

  • High Voltage/Current Rating: 1600V / 330A

  • Low Vce(sat) (Low Conduction Losses)

  • Optimized Switching Characteristics

  • High Short-Circuit Withstand Capability (SCWT)

  • Integrated NTC Temperature Sensor

  • Low-Inductance, Robust Package

  • Industrial Grade Durability

Applications

  • High-Power Industrial Inverters and Drives: For applications like large pumps and compressors.

  • Uninterruptible Power Supplies (UPS): High-power three-phase systems for critical infrastructure.

  • Solar Inverters: Central inverters for photovoltaic power plants.

  • Power Quality Equipment: Such as Active Power Filters (APF) and Static VAR Compensators (SVC).

Description
The ST330C16C0 is a high-voltage, high-current half-bridge IGBT module engineered for demanding industrial power conversion systems. It features a robust 1600V blocking voltage and a 330A current rating, making it suitable for applications requiring high power handling under elevated voltage conditions. The module utilizes advanced IGBT and diode chips to achieve a low collector-emitter saturation voltage (Vce(sat)) for efficient power conduction and optimized switching performance to control losses. It is designed for maximum reliability, offering high short-circuit ruggedness, an integrated NTC thermistor for accurate thermal monitoring, and a robust package construction to withstand the rigors of industrial environments.
Technical Specifications
category
Discrete semiconductor products
thyristors
SCR
manufacturer
Vishay General Semiconductor - Diodes Division
series
-
Packaging
Bulk
Part status
Discontinued
Voltage - Fault state
1.6 kV
Voltage - Gate Trigger (Vgt) (Max)
3 V
Current - Gate Trigger (IGT) (Max)
200 mA
Voltage - On-State (Vtm) (Max)
1.96 V
Current - On-State (It (AV)) (Max)
720 A
Current - Normal State (It (RMS)) (Max)
1420 A
Current - Hold (Ih) (max)
600 mA
Current - Fault State (Max)
50 mA
Current - Non-repeating surge 50, 60Hz (Itsm)
9000A,9420A
SCR type
Standard recovery
Operating temperature
-40°C ~ 125°C
Mounting type
Clamp style
Package/Enclosure
TO-200AB,E-PUK
Vendor device packages
TO-200AB(E-Puk)
Base product number
ST330
Drawing
VS-ST330C16C0 1600V 330A Half-Bridge Module Low Vce(sat) Low Loss High Short Circuit Ruggedness Integrated NTC For Industrial Inverters and High Power UPS
Our Advantages
  • High quality products - our offers are 100% new and original, ROHS compliant
  • Competitive price - good purchase channels with good price
  • Professional service - strict quality testing before shipment, and perfect after-sales service
  • Adequate inventory - supported by our strong purchasing team
  • Fast delivery - we ship goods within 1-3 working days after payment confirmation

Be sure to meet your need for all kinds of components.

Product List

Supply a Series of Electronic Components, full range of semiconductors, active andamp; passive Components. We can help you to get all for BOM of the PCB. In a word, you can get one-stop solution here.

The offers including:

Integrated Circuit, Memory ICs, Diode, Transistor, Capacitor, Resistor, Varistor, Fuse, Trimmer andamp; Potentiometer, Transformer, Battery, Cable, Relay, Switch, Connector, Terminal Block, Crystal andamp; Oscillator, Inductor, Sensor, Transformer, IGBT Driver, LED, LCD, Convertor, PCB (Printed Circuit Board), PCBA (PCB Assembly)

Strong in Brand:

Microchip, MAX, AD, TI, ATMEL, ST, ON, NS, Intersil, Winbond, Vishay, ISSI, Infineon, NEC, FAIRCHILD, OMRON, YAGEO, TDK, etc.
