Stars CL261Pro 125kW/261kWh PV –Storage –Diesel Integrated ESS Cabinet
Stars CL261Pro 125kW/261kWh PV –Storage –Diesel Integrated ESS Cabinet
Specifications
Model Number :
Stars CL261Pro
Certification :
IEC/EN 62619,IEC 62477,IEC 60529,IEC 61000-6-2,IEC 61000-6-4,UN38.3
Price :
Negotiable
DC Voltage Range :
728~936V
Battery Type :
LFP 3.2V/314Ah
On/Off-Grid Switch Time :
10ms
Payment Terms :
L/C,T/T
Rated Energy :
261.2KWh
PV Input :
250kW(DC),10MPPTs(20S)MC4,150~950V
Brand Name :
Wenergy
MOQ :
Negotiable
Load Power :
125kW
Description
Stars CL261Pro PV –Storage –Diesel Integrated ESS Cabinet
  • Plug-and-play modular design with parallel expansion
  • Intelligent iBMS with SOC/SOP calibration
  • IP55, C4H protection, and multi-layer battery safety
  • 100% unbalanced load support with seamless grid/off-grid switching
  • Up to 10 PV inputs, diesel integration, and multiple operating modes
Product Parameters
Model Stars CL261 Stars CL261Pro Stars CL261STS
Battery Type LFP 3.2V/314Ah
Rated Energy 261.2KWh
Battery Configuration 1P260S
DC Voltage Range 728~936V
Load Power 125kW
Grid Power / 187kW 250kW
DG Power / 187kW
PV Input / 250kW(DC),10MPPTs(20S)MC4,150~950V
On/Off-Grid Switch Time / 10ms
IP Level IP55(Complete System)
Corrosion-Proof Grade C4H
Cooling Type Intelligent Liquid Cooling (with Automatic Refilling)
Operating Temp.Range -35℃~55℃(>45℃ Derating)
Operating Altitude ≤2000m(>2000m Derating)
Relative Humidity 0-95%(Non-condensing)
Noise ≤70dB,≤60dB (Silent Version) ≤75dB
Communication Interface LAN/RS485
Communication Protocol Modbus,IEC104,MQTT
Operating Modes On-Grid,Off-Grid On-Grid,Off-Grid,On/Off-Grid Switching
Dimensions(W*D*H) 1012*1350*2270mm(±10mm) 1520*1350*2270mm
Weight ≤2.5t ≤2.7t ≤2.9t
Fire Protection System Pack-level Aerosol+Cluster-level Aerosol+Water Fire Suppression(Optional)+
Explosion Venting(Optional)+Active Early Warming
Cycle Life ≥8000(EoL70%SOH)
Certifications IEC/EN 62619,IEC 62477,IEC 60529,IEC 61000-6-2,IEC 61000-6-4,UN38.3
Installation Floor-Mounted
