4130 Steel Seamless Steel Casing Oil Well Drilling Pipe with 30-139.7mm OD Range and Stress Relief Annealed
4130 Steel Seamless Steel Casing Oil Well Drilling Pipe with 30-139.7mm OD Range and Stress Relief Annealed
4130 Steel Seamless Steel Casing Oil Well Drilling Pipe with 30-139.7mm OD Range and Stress Relief Annealed
4130 Steel Seamless Steel Casing Oil Well Drilling Pipe with 30-139.7mm OD Range and Stress Relief Annealed
4130 Steel Seamless Steel Casing Oil Well Drilling Pipe with 30-139.7mm OD Range and Stress Relief Annealed
4130 Steel Seamless Steel Casing Oil Well Drilling Pipe with 30-139.7mm OD Range and Stress Relief Annealed
4130 Steel Seamless Steel Casing Oil Well Drilling Pipe with 30-139.7mm OD Range and Stress Relief Annealed
4130 Steel Seamless Steel Casing Oil Well Drilling Pipe with 30-139.7mm OD Range and Stress Relief Annealed
Specifications
Brand Name :
HONGBAO
Model Number :
HG-OP
Certification :
PED, ISO9001, DNV
Place of Origin :
China
MOQ :
1MT
Price :
Negotiable
Payment Terms :
L/C,T/T
Supply Ability :
3000MT/Month
Delivery Time :
Negotiable
Packaging Details :
As required
Material :
30CrMo（4130/34CrMo4）, 42CrMo（4140/42CrMo4）, 40Mn2, 45MnMoB, 30CrMnSiA, 4135, 1541
Standard :
GB/T 9808, ASTM A519, DIN2391, EN10305-1,
OD Range :
30-139.7mm
WT Range :
3-19mm
Description
Oilfield Seamless Steel Casing Drill Rod 4130 Steel Oil Well Drilling Pipe
High-Performance Oil & Gas Drilling Pipes (4130 Grade) - Key Features & Benefits
Superior Mechanical Strength
  • Tensile Strength: ≥813 MPa (Ensures resistance to burst/collapse under high downhole pressures)
  • Yield Strength: ≥690 MPa (Withstands heavy loads during drilling operations without permanent deformation)
Excellent Ductility & Toughness
  • Elongation: ≥15% (Absorbs shock loads and vibrations, reducing the risk of brittle fracture in harsh environments)
Optimized Hardness (≥24 HRC)
  • Balanced hardness for wear resistance (protects against abrasion from drilling cuttings) while maintaining machinability and impact toughness
Reliable Delivery Condition (+SR: Stress Relief Annealed)
  • Stress relief annealing minimizes internal stresses from manufacturing, ensuring dimensional stability and preventing cracking during service
Proven Alloy Composition (4130 Steel)
  • Chromium-Molybdenum (Cr-Mo) alloy enhances:
    • Fatigue resistance (critical for cyclic loading in extended reach drilling)
    • Corrosion resistance (better than carbon steel in mildly aggressive fluids)
    • Weldability (simplifies field repairs/joints)
Ideal for Demanding Applications
  • Suitable for oil/gas well drilling, geothermal wells, and mineral exploration where high strength-to-weight ratio and reliability are paramount
Why Choose Our 4130 Drilling Pipes?
  • Higher Safety - Lower risk of failure under extreme pressures/temperatures
  • Cost-Effective - Balances performance and affordability compared to premium alloys (e.g., 4140)
  • Global Standards Compliance - Meets API and industry specifications for critical drilling operations
Chemical Composition
Steel Grade C Si Mn P S Cr Mo B
4130 0.28-0.33 0.15-0.35 0.40-0.60 ≤0.040 ≤0.040 0.80-1.10 0.15-0.25
4140 0.38-0.43 0.15-0.35 0.75-1.00 ≤0.040 ≤0.040 0.80-1.10 0.15-0.25
45MnMoB 0.43-0.48 0.17-0.37 1.05-1.35 ≤0.020 ≤0.015 0.20-0.25 0.001-0.005
1541 0.36-0.44 - 1.35-1.65 ≤0.040 ≤0.050
30CrMnSiA 0.28-0.34 0.90-1.20 0.80-1.10 ≤0.020 ≤0.015 0.80-1.10
Mechanical Properties
Steel Grade Deliver Condition Tensile Strength (MPa) Yield Strength (MPa) Elongation (%) Hardness (HRC)
4130 + SR ≥813 ≥690 ≥15% ≥24
4140 QT ≥950 ≥850 ≥14% 28 - 33
45MnMoB + N ≥790 ≥600 ≥14% -
1541 + SR ≥813 ≥690 ≥15% ≥24
30CrMnSiA QT ≥850 ≥750 ≥14% 26 - 31
4130 Steel Seamless Steel Casing Oil Well Drilling Pipe with 30-139.7mm OD Range and Stress Relief Annealed 4130 Steel Seamless Steel Casing Oil Well Drilling Pipe with 30-139.7mm OD Range and Stress Relief Annealed 4130 Steel Seamless Steel Casing Oil Well Drilling Pipe with 30-139.7mm OD Range and Stress Relief Annealed
Frequently Asked Questions
Can you provide a sample to check the quality?
We can provide free sample with same or similar sizes for you to check tube quality. You need to in charge of Express costs.
How about your production capacity?
3000 tons/Month.
What are your terms of payment?
30%TT in advance, Balance to be paid before shipment.
Where is your factory?
Zhangjiagang city, 1.5 hours away from Shanghai.
How can I get the quotation A.S.A.P?
Please send us an inquiry with full details as following, quotation will sent to you A.S.A.P:
  • Tube Standard
  • Steel Grade
  • Tube Size and Size Tolerance
  • Tube length
  • Quantity
  • If any special requirements
How about the minimum order quantity?
Normally for one size above 1 ton.
Welcome to contact us! Thanks.
