ASTM A513 A519 Cold Drawn Seamless Drill Rod Tube 30CrMo Steel Oil Well Drilling Pipe With Low Eccentricity
ASTM A513 A519 Cold Drawn Seamless Drill Rod Tube 30CrMo Steel Oil Well Drilling Pipe With Low Eccentricity
ASTM A513 A519 Cold Drawn Seamless Drill Rod Tube 30CrMo Steel Oil Well Drilling Pipe With Low Eccentricity
ASTM A513 A519 Cold Drawn Seamless Drill Rod Tube 30CrMo Steel Oil Well Drilling Pipe With Low Eccentricity
ASTM A513 A519 Cold Drawn Seamless Drill Rod Tube 30CrMo Steel Oil Well Drilling Pipe With Low Eccentricity
ASTM A513 A519 Cold Drawn Seamless Drill Rod Tube 30CrMo Steel Oil Well Drilling Pipe With Low Eccentricity
ASTM A513 A519 Cold Drawn Seamless Drill Rod Tube 30CrMo Steel Oil Well Drilling Pipe With Low Eccentricity
ASTM A513 A519 Cold Drawn Seamless Drill Rod Tube 30CrMo Steel Oil Well Drilling Pipe With Low Eccentricity
Specifications
Brand Name :
HONGBAO
Model Number :
HG-OP
Certification :
PED, ISO9001, DNV
Place of Origin :
China
MOQ :
1MT
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
3000MT/Month
Delivery Time :
Negotiable
Packaging Details :
As required
Material :
30CrMo（4130/34CrMo4）, 42CrMo（4140/42CrMo4）, 40Mn2, 45MnMoB, 30CrMnSiA, 4135, 1541
Standard :
GB/T 9808, ASTM A519, DIN2391, EN10305-1,
OD Range :
30-139.7mm
WT Range :
3-19mm
Processing :
Cold Rolling
Color :
Black
Description

30CrMo/34CrMo4 4130 Grade Drilling Pipe – Balanced Strength & Weldability for Versatile Oilfield Applications​​

​​ Engineered for conventional to mid-depth oilfield wells​​, 4130 grade drilling pipe delivers ​​optimal strength, weldability, and cost efficiency​​ – making it the reliable choice for diverse drilling operations.

​​Key Features & Benefits​​

1. ​​Balanced High Strength​​ - ​Tensile strength ≥813 MPa, Yield strength ≥690 MPa​​ – Provides ​​reliable load-bearing capacity​​ for medium-depth wells (≤3,000m) and standard pressure conditions (≤35 MPa), ensuring structural integrity during drilling.

2. ​​Superior Weldability​​ - ​​Low carbon content with chromium-molybdenum (Cr-Mo) alloying​​ – Enables ​​easy field welding​​ (minimal preheat/post-weld heat treatment required) while maintaining toughness, ideal for on-site casing connections or repairs.

3. ​​Controlled Toughness & Ductility​​ - ​​Elongation ≥15%​​ – Absorbs ​​dynamic loads​​ (e.g., bit vibration, pressure fluctuations) and resists brittle fracture, ensuring operational safety in varied well conditions.

4. ​​Cost-Effective Performance​​ - ​​Moderate alloy cost (Cr-Mo optimized)​​ – Delivers ​​premium-grade strength at a lower price point than 4140​​, balancing performance and budget for conventional to mid-range wells.

5. ​​Proven Reliability​​ - Widely used in ​​onshore/offshore conventional wells, water wells, and geothermal projects​​ – Backed by decades of field performance in stable to moderately complex formations.

​​Why 4130?​​

1. ​​Versatile Mid-Range Performance​​ – Ideal for ​​wells ≤3,000m with standard pressure/temperature​​ , avoiding over-engineering of high-end grades (e.g., 4140).

2. ​​Weld-Friendly & Easy to Maintain​​ – Simplifies ​​field operations​​ (e.g., welding, threading) without sacrificing strength, reducing downtime and costs.

3. ​​Better Than Carbon Steel​​ – Outperforms basic carbon steels (e.g., 1541) in ​​strength, fatigue resistance, and corrosion resistance​​ (mild environments).

Suitable for mine blasting, water well drilling, geothermal well drilling, fore poling, and mining of coal and nonferrous metals.​

Chemical Composition

Steel Grade C Si Mn P S Cr Mo B

4130

 0.28-0.33 0.15-0.35 0.40-0.60 ≤0.040 ≤0.040 0.80-1.10 0.15-0.25
4140 0.38-0.43 0.15-0.35 0.75-1.00 ≤0.040 ≤0.040 0.80-1.10 0.15-0.25
45MnMoB 0.43-0.48 0.17-0.37 1.05-1.35 ≤0.020 ≤0.015 0.20-0.25 0.001-0.005

1541

 0.36-0.44 - 1.35-1.65 ≤0.040 ≤0.050

30CrMnSiA

 0.28-0.34 0.90-1.20 0.80-1.10 ≤0.020 ≤0.015 0.80-1.10

Mechanical Properties

Steel Grade Deliver Condition

Tensile Strength(Mpa)

Yield Strength(Mpa)

Elongation(%)

 Hardness(HRC)
4130 + SR ≥813 ≥690 ≥15% ≥24
4140 QT ≥950 ≥850 ≥14% 28 - 33
45MnMoB + N ≥790 ≥600 ≥14% -
1541 + SR ≥813 ≥690 ≥15% ≥24
30CrMnSiA QT ≥850 ≥750 ≥14% 26 - 31

Delivery Condition:

1.Stress Relief Annealing after Cold Working (+SR) (BKS)

2.Normalizing (+N) (NBK)

3.Quenching & Tempering (QT)

ASTM A513 A519 Cold Drawn Seamless Drill Rod Tube 30CrMo Steel Oil Well Drilling Pipe With Low Eccentricity

FAQ:

1. Can you provide a sample to check the quality?
We can provide free sample with same or similar sizes for you to check tube quality.
You need to in charge of Express costs.

2. How about your production capacity?
3000 tons/Month.

3. What are your terms of payment?
30%TT in advance, Balance to be paid before shipment.

4. Where is your factory?
Zhangjiagang city, 1.5 hours away from Shanghai.

5. How can I get the quotation A.S.A.P?
Please send us an inquiry with full details as following,quotation will sent to you A.S.A.P:
1). Tube Standard
2). Steel Grade
3). Tube Size and Size Tolerance
4). Tube length
5). Quantity
6). If any special requirements

6. How about the minimum order quantity?
Normally for one size above 1 ton.

Welcome to contact us! Thanks.
