ASTM A519 Seamless Casing Steel Tube 1541 Steel Grade Oil Well Drilling Pipe With Low Residual Hoop Stresses
ASTM A519 Seamless Casing Steel Tube 1541 Steel Grade Oil Well Drilling Pipe With Low Residual Hoop Stresses
ASTM A519 Seamless Casing Steel Tube 1541 Steel Grade Oil Well Drilling Pipe With Low Residual Hoop Stresses
ASTM A519 Seamless Casing Steel Tube 1541 Steel Grade Oil Well Drilling Pipe With Low Residual Hoop Stresses
ASTM A519 Seamless Casing Steel Tube 1541 Steel Grade Oil Well Drilling Pipe With Low Residual Hoop Stresses
ASTM A519 Seamless Casing Steel Tube 1541 Steel Grade Oil Well Drilling Pipe With Low Residual Hoop Stresses
ASTM A519 Seamless Casing Steel Tube 1541 Steel Grade Oil Well Drilling Pipe With Low Residual Hoop Stresses
ASTM A519 Seamless Casing Steel Tube 1541 Steel Grade Oil Well Drilling Pipe With Low Residual Hoop Stresses
Specifications
Brand Name :
HONGBAO
Model Number :
HG-OP
Certification :
PED, ISO9001, DNV
Place of Origin :
China
MOQ :
1MT
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
3000MT/Month
Delivery Time :
Negotiable
Packaging Details :
As required
Material :
30CrMo（4130/34CrMo4）, 42CrMo（4140/42CrMo4）, 40Mn2, 45MnMoB, 30CrMnSiA, 4135, 1541
Standard :
GB/T 9808, ASTM A519, DIN2391, EN10305-1,
OD Range :
30-139.7mm
WT Range :
3-19mm
Processing :
Cold Rolling
Color :
Black
Description

1541 Grade Drilling Pipe Product Advantages – Technical Performance Overview​​
The ​​1541-grade drilling pipe​​ is engineered for oilfield applications requiring a ​​balance of strength, toughness, and cost-effectiveness​​. Based on its ​​key material parameters (carbon-manganese steel composition)​​ and performance characteristics, here are its ​​distinct product advantages​​ compared to conventional grades (e.g., 4130/4140 for high-end scenarios or lower-grade carbon steels):

​​Core Material Composition & Performance Basis​​
1541 grade is a ​​high-quality carbon-manganese (C-Mn) steel​​, typically containing:

​1.​ Carbon (C): 0.38–0.43%​​ (higher than standard carbon steels, enhancing strength);

2. ​​Manganese (Mn): 1.30–1.60%​​ (improves hardenability and toughness);

3. ​​Low alloy content​​ (no chromium/molybdenum as in 4140, but optimized for cost-sensitive drilling).

Why Choose 1541-Grade Drilling Pipes?​​
1. Balanced Performance​​: Delivers “just enough” strength and toughness for most common drilling needs without over-engineering;

2. Cost Savings​​: Lower material and processing costs translate to reduced total drilling expenses;

3. Field-Friendly​​: Easy welding, machining, and connection handling for faster operations;

4. Proven Reliability​​: Widely used in mature oilfields and routine drilling projects with decades of field validation.

​​1541-Grade Drilling Pipes – The Practical Choice for Efficient, Cost-Effective Oilfield Operations.​​

Applications include fore poling (advance support), mine blasting, water well drilling, geothermal well drilling, and coal/nonferrous metal mining.​​

Chemical Composition

Steel Grade C Si Mn P S Cr Mo B

4130

 0.28-0.33 0.15-0.35 0.40-0.60 ≤0.040 ≤0.040 0.80-1.10 0.15-0.25
4140 0.38-0.43 0.15-0.35 0.75-1.00 ≤0.040 ≤0.040 0.80-1.10 0.15-0.25
45MnMoB 0.43-0.48 0.17-0.37 1.05-1.35 ≤0.020 ≤0.015 0.20-0.25 0.001-0.005

1541

 0.36-0.44 - 1.35-1.65 ≤0.040 ≤0.050

30CrMnSiA

 0.28-0.34 0.90-1.20 0.80-1.10 ≤0.020 ≤0.015 0.80-1.10

Mechanical Properties

Steel Grade

 Deliver Condition Tensile Strength(Mpa) Yield Strength(Mpa) Elongation(%) Hardness(HRC)
4130 + SR ≥813 ≥690 ≥15% ≥24
4140 QT ≥950 ≥850 ≥14% 28 - 33
45MnMoB + N ≥790 ≥600 ≥14% -
1541 + SR ≥813 ≥690 ≥15% ≥24
30CrMnSiA QT ≥850 ≥750 ≥14% 26 - 31

Delivery Condition:

1. Stress Relief Annealing after Cold Working (+SR) (BKS)

2. Normalizing (+N) (NBK)

3. Quenching & Tempering (QT)
