Specifications
Brand Name :
Hongbao
Model Number :
HBWS-001
Certification :
TS16949, ISO9001
Place of Origin :
Jiangsu, China
MOQ :
1 ton
Price :
Negotiable
Supply Ability :
800MT/Month
Delivery Time :
Negotiable
Packaging Details :
Wooden Cases
Payment Terms :
L/C,T/T
Material :
St52, St45, St35
Length :
Random or fixed length
Shape :
Round
Technical :
Seamless or welded
Standard :
EN10305-1, EN10305-2 etc
High Light :
Welded steel pipe
Description
ST52 EN10305-2 WT0.5 Precision Steel Tubes Mechanical Welded Steel Tube
Product Overview

Precision steel tubes, specifically mechanical welded steel tubes, are engineered for high strength and durability. They feature seamless construction that ensures uniformity and dimensional accuracy, essential for various applications. These tubes exhibit excellent resistance to corrosion and wear, making them suitable for demanding environments. Their precision manufacturing process allows for lightweight yet robust designs, ideal for automotive, construction, and industrial uses. With superior weld integrity and consistent performance, these tubes provide reliability and efficiency in mechanical systems, enhancing overall operational effectiveness.

Technical Specifications
Standard: EN10305-1, EN10305-2, EN10305-4, etc.
Grade: St52, St45, ST35
Thickness: 0.5-15 mm
Section Shape: Round
Outer Diameter: 4-120 mm
Place of Origin: Jiangsu, China (Mainland)
Technique: Cold Drawn
Certification: TS16949, ISO9001
Alloy Type: Non-alloy
Material: ST35, ST45, ST52
Quality: Non-secondary
Machining Specifications
Material ST37.4, ST52.4, E235, E355
Standard DIN2391, EN10305
Delivery Condition +C, +LC, +SR, +N, +A
Size Range Outer Diameter: φ6-φ120 mm
Wall Thickness: 0.5-15 mm
Application High Precision Steel Tube is widely used in automotive parts, hydraulic systems, and high-precision machining
Production Process

Cold rolling by Cold pilger machine and Cold rolling machine

Delivery Conditions
  • +C: No heat treatment after the final cold drawing process
  • +LC: After the final heat treatment there is a suitable drawing pass
  • +SR: After the final cold drawing process there is a stress relieve heat treatment in a controlled atmosphere
  • +A: After the final cold drawing process the tubes are annealed in a controlled atmosphere
  • +N: After the final cold drawing operation the tubes are normalized in a controlled atmosphere
Production Method

The cold drawn welded tube is produced by drawing ERW (electric resistance welded tube). During this process the sizing (wall thickness, inside and outside diameter), as well as weld integrity and surface finish is closely controlled to produce tube of the required size and mechanical property characteristics.

Key Advantages
  • Better shape and dimensional accuracy
  • Improved quality surface finish
  • Tight eccentricity and wall thickness tolerances
  • Enhanced tube safety
  • Good toughness at low temperatures
  • 90% of cylinders in the USA market are produced with welded tubes
  • Cost-effective fixed lengths
