Integrated Coagulation Flocculation Lamella Clarifier 20-80m³/h for Wastewater Treatment Plant Combined System
Integrated Coagulation Flocculation Lamella Clarifier 20-80m³/h for Wastewater Treatment Plant Combined System
Integrated Coagulation Flocculation Lamella Clarifier 20-80m³/h for Wastewater Treatment Plant Combined System
Integrated Coagulation Flocculation Lamella Clarifier 20-80m³/h for Wastewater Treatment Plant Combined System
Specifications
Model Number :
LST-80
MOQ :
1 Set
Coagulation Zone :
Integrated Rapid Mix Chamber with Mechanical Stirrer
Inclination Angle :
55°-60°
Flocculation Zone :
Integrated Slow Mix Chamber with Paddle Flocculator
Payment Terms :
T/T,L/C,Western Union
Delivery Time :
25-40 working days after order confirmation
Inlet SS Concentration :
≤ 10000 mg/L
Application :
Municipal Sewage, Industrial Process Water, Mining Effluent
Brand Name :
DUBHE
Certification :
ISO 9001:2015
Plate Spacing :
50-80 mm
Outlet SS Concentration :
≤ 20 mg/L
Price :
USD 12,000 - 35,000 / Set
Chemical Dosing :
PAC / PAM / FeCl3 Compatible Dosing Ports
Place of Origin :
Jiangsu, China
Packaging Details :
Heavy-duty export plywood crate with anti-corrosion wrapping, desiccant packs, and reinforced steel strapping for ocean container freight
Plate Material :
PP (Polypropylene) / Stainless Steel 304
Processing Capacity :
20-80 m³/h
Supply Ability :
25 Sets per Month
Tank Material :
Carbon Steel with Multi-Layer Epoxy Coating
Description

Integrated Coagulation Flocculation Lamella Clarifier 20-80m³/h for Wastewater Treatment Plant Combined SystemIntegrated Coagulation Flocculation Lamella Clarifier 20-80m³/h for Wastewater Treatment Plant Combined System

Integrated Coagulation Lamella Clarifier for Complete Wastewater Treatment

Our Integrated Coagulation Lamella Clarifier (Model BLCF-80) combines coagulation, flocculation, and inclined plate sedimentation into a single unified system. This all-in-one design eliminates the need for separate tanks and interconnecting piping, reducing installation cost, footprint, and commissioning time. Processing 20-80 m³/h, it is the preferred solution for municipal water authorities and industrial plants across Brazil, Mexico, Argentina, Chile, Colombia, and Peru.

Key Features & Benefits

  • Three-Stage Integration: Rapid mixing (coagulation) + slow mixing (flocculation) + inclined plate settling, all in one compact tank. Chemical dosing ports are pre-installed for PAC, PAM, and FeCl3.
  • Optimized Process Control: Independent variable-speed mechanical stirrers for coagulation and flocculation zones allow precise adjustment of G-values and detention times for varying influent characteristics.
  • Superior Effluent Quality: Achieves outlet suspended solids ≤ 20 mg/L and turbidity ≤ 3 NTU with proper chemical conditioning, meeting CONAMA 430/2011 and NOM-001-SEMARNAT discharge limits.
  • Plug-and-Play Installation: Factory pre-assembled and tested. On-site installation requires only inlet, outlet, sludge, and chemical connections, reducing commissioning from weeks to days.
  • Flexible Material Options: Carbon steel with epoxy coating for standard applications, stainless steel 304 for corrosive industrial effluents including mining and chemical processing.

Technical Specifications

Model

Capacity

Dimension (m)

Sludge scraper

Nozzle list (DN) GB/JIS/ANSI

LST 2

m³/h

L

W

H₁/H₂

kW

Inlet
(a)

Outlet
(b)

Sludge outlet
(c)

Backwash
(d)

005-7

5

2.2

1.7

3.2/2.4

0.25

80

50

50

50

010-11

10

2.9

1.7

3.2/2.4

0.25

100

80

50

50

015-21

15

2.8

2.2

3.8/3.0

0.25

100

80

80

50

020-30

20

3.5

2.2

3.8/3.0

0.25

150

150

100

50

035-43

35

3.9

2.2

4.3/3.5

0.25

200

150

100

50

040-52

40

3.8

2.8

4.3/3.5

0.25

200

200

100

50

055-72

55

4.4

2.8

4.3/3.5

0.25

250

250

100

50

065-82

65

4.2

3.3

4.3/3.5

0.25

250

250

100

50

080-105

80

4.9

3.3

4.3/3.5

0.25

250

250

100

50

※070-95

70

6.6

2.2

4.3/3.5

0.25*2

250

250

100

50

※120-150

120

7.7

2.8

4.4/3.6

0.25*2

300

300

100

50

※180-215

180

8.5

3.3

4.4/3.6

0.25*2

350

350

100

50

Ideal for Latin American Infrastructure Projects

Our integrated clarifiers are currently treating municipal drinking water in Quito, Ecuador, industrial effluent in Monterrey, Mexico, and mining process water in Antofagasta, Chile. We provide complete process design packages including mass balance diagrams, P&ID, and equipment layout drawings in Spanish and Portuguese. Our local service partners offer on-site commissioning, operator training, and annual maintenance contracts throughout the region.

Request a comprehensive technical proposal today. We offer free jar testing guidelines and chemical dosing optimization to maximize your clarifier performance.
