Industrial Wastewater Treatment Lamella Clarifier Inclined Plate Settler for Food Processing WWTP Plants
Industrial Wastewater Treatment Lamella Clarifier Inclined Plate Settler for Food Processing WWTP Plants
Specifications
Brand Name :
DUBHE
DAF Compatibility :
Full integration with upstream DAF system
Plate Material :
SS304/SS316L/PVC/PP
Place of Origin :
China
Certification :
ISO 9001:2015
Payment Terms :
T/T,L/C
Capacity :
5-180 m³/hr
Model Number :
LST-DAF-1
Delivery Time :
30-50 working days
Packaging Details :
Export-grade plywood crate with anti-corrosion wrapping, reinforced steel frame for ocean freight
Price :
USD 8,000-25,000 / Set
Inclined Plate Angle :
55°-60°
Supply Ability :
20 Sets per Month
Application :
Food processing/meat processing/dairy/municipal wastewater
Sludge Scraper Power :
0.25 kW
MOQ :
1 Set
Description
Wastewater Treatment Lamella Clarifier for WWTP
Key Advantages & Features

  • High-Efficiency Inclined Plate Design

    Advanced shallow-pool inclined plate technology delivers 6-10 times higher settling efficiency than conventional clarifiers, ideal for high-load food processing wastewater treatment plants (WWTP).

  • Seamless WWTP Integration

    Engineered as the perfect downstream sedimentation stage for DAF systems, capturing residual solids to produce crystal-clear effluent for discharge or reuse.

  • Compact Footprint for Urban Plants

    Reduces required area by up to 80% compared to horizontal sedimentation tanks, lowering civil works and installation costs for space-constrained WWTP facilities.

  • Anti-Clogging Plate Spacing

    Optimized wide plate spacing with integrated backwash prevents sludge accumulation and ensures uninterrupted operation in high-fat food processing environments.

  • Automated Sludge Discharge

    Dead-zone-free sludge hoppers with mechanical scraper deliver continuous, reliable sludge removal without operator intervention.

  • Corrosion-Resistant Construction

    Built with SS304/SS316L stainless steel or industrial-grade PVC/PP plates for exceptional durability in aggressive wastewater environments.

Target Industries in Latin America

  • Meat & Poultry Processing

    High-strength wastewater with blood, fat, and protein residues from slaughterhouses across Brazil, Argentina, and Mexico.

  • Dairy Processing

    Whey, milk solids, and CIP wash water treatment for dairy cooperatives throughout Latin America.

  • Fruit & Vegetable Processing

    High-suspended-solids wash water and peeling effluent from tropical fruit processors and juice plants.

  • Beverage & Brewery

    High-COD effluent treatment for soft drink, juice, and brewery WWTP discharge compliance.

Technical Specification
Model Capacity Dimension (m) Sludge scraper Nozzle list (DN) GB/JIS/ANSI
LST 2 m³/h L W H₁/H₂ kW Inlet
(a)		 Outlet
(b)		 Sludge outlet
(c)		 Backwash
(d)
005-7 5 2.2 1.7 3.2/2.4 0.25 80 50 50 50
010-11 10 2.9 1.7 3.2/2.4 0.25 100 80 50 50
015-21 15 2.8 2.2 3.8/3.0 0.25 100 80 80 50
020-30 20 3.5 2.2 3.8/3.0 0.25 150 150 100 50
035-43 35 3.9 2.2 4.3/3.5 0.25 200 150 100 50
040-52 40 3.8 2.8 4.3/3.5 0.25 200 200 100 50
055-72 55 4.4 2.8 4.3/3.5 0.25 250 250 100 50
065-82 65 4.2 3.3 4.3/3.5 0.25 250 250 100 50
080-105 80 4.9 3.3 4.3/3.5 0.25 250 250 100 50
※070-95 70 6.6 2.2 4.3/3.5 0.25*2 250 250 100 50
Why Choose DUBHE for Latin American WWTP


DUBHE LST-DAF series wastewater treatment lamella clarifiers are purpose-built for Latin American food processing WWTP requirements, meeting Brazilian CONAMA 430, Mexican NOM-001-SEMARNAT, and Chilean DS 90 discharge standards.



Local Support: Technical support network across Brazil, Mexico, Argentina, and Colombia with Spanish and Portuguese documentation and regionally stocked spare parts.



Proven Performance: Achieves 95%+ TSS removal and reduces chemical consumption by up to 30% when combined with upstream DAF systems.
