Door-to-Door Serviced Panelized Walk-In Climatic Chamber | Temperature and Humidity Test Room
Door-to-Door Serviced Panelized Walk-In Climatic Chamber | Temperature and Humidity Test Room
Door-to-Door Serviced Panelized Walk-In Climatic Chamber | Temperature and Humidity Test Room
Door-to-Door Serviced Panelized Walk-In Climatic Chamber | Temperature and Humidity Test Room
Door-to-Door Serviced Panelized Walk-In Climatic Chamber | Temperature and Humidity Test Room
Door-to-Door Serviced Panelized Walk-In Climatic Chamber | Temperature and Humidity Test Room
Door-to-Door Serviced Panelized Walk-In Climatic Chamber | Temperature and Humidity Test Room
Door-to-Door Serviced Panelized Walk-In Climatic Chamber | Temperature and Humidity Test Room
Specifications
Brand Name :
ASLI
Place of Origin :
Guangdong, China
MOQ :
1
Price :
$26,520
Power :
20KW
Voltage :
380 V
Protection Class :
IP55
Heating Speed :
3 C/min
Cooling Speed :
1 C/min
Control Accuracy :
+/-0.5C
Cooling System :
air cooling
Temperature Range :
Low Temperature: -700℃ to High Temperature: 800℃
Humidity Range :
20%~98% R.H.
Temperature Resolution :
0.1degree C
Humidity Resolution :
0.1% R.H.
Temperature Uniformity :
±2.5degree C
Humidity Uniformity :
±3.5% R.H.
Compressor Brand :
French Tecumseh, Germany Bizer
Power Supply :
AC 380 V(±10%),50/60HZ ,3 phase 5 Lines
Description
Door-to-Door Serviced Panelized Walk-In Climatic Chamber
Temperature and Humidity Test Room
ISO 9001-2015 certified manufacturer
RS-232, RS-485 serial communications • Stainless steel interior • USB Port for Data Storage • Door with heated viewing window & interior lights
Product Overview
Our modular walk-in environmental test chamber with comprehensive door-to-door service provides custom temperature and humidity control for reliability, stability, and climatic simulation testing. Suitable for low temperature, high temperature, temperature cycling, constant heat, and alternating heat testing applications.
The chamber features a block-type construction with elegant appearance and scientific wind tunnel design to meet diverse customer requirements. Equipped with touch screen interface and PLC program controller for precise control.
Applications
Ideal for quality inspection across multiple industries including electronics, electrical appliances, communications, instruments, automotive, plastics, metals, food, chemicals, building materials, medical devices, and aerospace products.
Door-to-Door Serviced Panelized Walk-In Climatic Chamber | Temperature and Humidity Test Room
Technical Specifications
Parameter Specification
Model THR-volume (low-temperature options: A ~ F)
Inner Dimensions Customer designated space size and design
Temperature Range Low Temperature (A:25℃ B:0℃, C:-200℃, D:-400℃, E:-600℃, F:-700℃) High Temperature 800℃ (80℃ ~200℃ optional)
Humidity Range 20%~98% R.H. (10%-98% R.H. / 5%-98% R.H. special optional with dehumidifier)
Indication Resolution / Distribution Uniformity 0.1°C ; 0.1% R.H. / ±2.5°C ; ±3.5% R.H.
Control Accuracy ±0.5°C ; ±2.5% R.H.
Temperature Rising/Falling Velocity Rising: 0.1~3.0°C/min; Falling: 0.3~1.0°C/min (Min. 1.5°C/min optional)
Cooling System Water cooled
Protection Devices Fuse-free switch, compressor overload protection, high/low voltage coolant protection, over-humidity & over-temperature protection, fuses, fault warning system, water shortage warning
Optional Accessories Slope for cart, Recorder, Water Purifier, Dehumidifier
Compressor French Tecumseh Brand, Germany Bizer Brand
Power AC 380 V(±10%), 50/60HZ, 3 phase 5 Lines
Door-to-Door Serviced Panelized Walk-In Climatic Chamber | Temperature and Humidity Test Room
Key Features
  • Double-insulated airtight container effectively isolates internal temperature
  • Separated humidifier and electric circuits enhance safety and protect against water leakage
  • High-performance fan motor provides greater cyclic airflow to eliminate dead corners
  • Independent heating, cooling, dehumidifying, and humidifying systems reduce testing costs and extend machine life
  • Refined silicone rubber door seals prevent leakage
  • Ultra-fine glass fiber or rigid polyurethane foam insulation minimizes energy loss
  • Audible buzzers signal malfunctions for prompt maintenance
  • Complies with international testing standards
Packaging & Delivery
Door-to-Door Serviced Panelized Walk-In Climatic Chamber | Temperature and Humidity Test Room
We provide professional, environmentally friendly, and efficient packaging services to ensure the complete safety of your goods during transportation.
Company Profile
Door-to-Door Serviced Panelized Walk-In Climatic Chamber | Temperature and Humidity Test Room
Our Main Products
Temperature Cycling Test Chamber • Thermal Shock Test Chamber • Salt Spray Test Chamber • PCT/HAST Acceleration Aging Chamber • High Frequency Vibration Shaker • Mechanical Shock Impact Tester • Drop Test Machine
Door-to-Door Serviced Panelized Walk-In Climatic Chamber | Temperature and Humidity Test Room
Frequently Asked Questions
Are you a trading company or a factory?
We are a factory + trade integration company with our own manufacturing facility.
Do you accept customization service?
Yes, we offer both standard machines and customized solutions designed to your specific requirements.
What is your product warranty?
1-year warranty with lifetime service support.
How about the product quality?
Our products comply with ISO, ASTM, GB, and other international standards.
For more information about our Panelized Walk-In Climatic Chamber, please don't hesitate to send your inquiry.
