≤22m³ Box Volume 5750W Cooling Capacity EV Truck Refrigeration Unit with Inner Grooved Copper Tube Aluminum Fin Evaporator
≤22m³ Box Volume 5750W Cooling Capacity EV Truck Refrigeration Unit with Inner Grooved Copper Tube Aluminum Fin Evaporator
≤22m³ Box Volume 5750W Cooling Capacity EV Truck Refrigeration Unit with Inner Grooved Copper Tube Aluminum Fin Evaporator
≤22m³ Box Volume 5750W Cooling Capacity EV Truck Refrigeration Unit with Inner Grooved Copper Tube Aluminum Fin Evaporator
Specifications
Compressor Displacement :
PAG 68
Cooling Capacity(-18℃) :
3380W
Refrigerant Charge :
1.8 KG
Application Box Volume :
≤22 m3
Cooling Capacity(0℃) :
5750W
Temperature Range :
-25°C To +25°C
Brand Name :
Yinhuasheng/OEM
Model Number :
EV-600
Certification :
CE/ISO9001
Place of Origin :
China
MOQ :
1SET
Price :
Negotiable
Payment Terms :
TT/LC
Supply Ability :
100 sets per month
Delivery Time :
Negotiable
Packaging Details :
Negotiable
Description
≤22m³ EV Truck VAN Electric Refrigeration Unit
Powered by the vehicle battery, our EV-600 unit is specially designed for NEV full electric trucks. This refrigeration unit is widely used for reefer truck boxes up to 22m³ in volume. The embedded evaporator design does not occupy interior space of the carriage.
Standard Features
  • Applicable for small and medium sized new energy vehicles
  • High grade (IP67) water-proof and insulation design, AC-DC interlock and four in one design
  • Ultra-slim fiberglass evaporator or Al-alloy evaporator, with big air flow
  • Fully enclosed electric compressor: high efficiency, eco-friendly, not affected by vehicle speed
  • The compressor is inbuilt inside the condenser unit, compact design
  • Multi-functional LCD controller, precise temperature control, full display and easy operation, with fault codes and alarms
  • No interference between charging and unit running, saving charging time and extending battery service life
  • HP and LP switch safety protection
  • Standard AC220V standby for parking cooling
Technical Parameters
Parameter Specification
Unit Model EV-600
Applicable Temperature -25℃ ~ +25℃
Box Volume ≤22m³
Cooling Capacity (0℃) 5750 W
Cooling Capacity (-18℃) 3380 W
Compressor Lubricating Oil PAG 68
Evaporator Material Inner grooved copper tube
Evaporator Fans 2 PCS
Condenser Material Parallel flow condenser
Condenser Fans 2 PCS
High Voltage DC250V-DC450V/DC380V-DC750V
Low Voltage Power DC-DC
Control Voltage DC12V(9-16V)/DC24V(16-32V)
Refrigerant R404a
Refrigerant Charge 1.8 KG
Box Temperature Adjustment Electronic digital display
Safety Protection High and low pressure switch
Defrosting Hot gas defrost automatically
Drive Model Full electric driven
Evaporator Weight 24.5 KG
Condenser Weight <90 KG
Evaporator Dimensions 1130×650×220
Condenser Dimensions 1500×650×530
