EV300 Vehicle Refrigeration Unit with -25°C to +25°C Temperature Range, Parallel Flow Condenser, and IP67 Waterproof Design for Electric Trucks
EV300 Vehicle Refrigeration Unit with -25°C to +25°C Temperature Range, Parallel Flow Condenser, and IP67 Waterproof Design for Electric Trucks
EV300 Vehicle Refrigeration Unit with -25°C to +25°C Temperature Range, Parallel Flow Condenser, and IP67 Waterproof Design for Electric Trucks
EV300 Vehicle Refrigeration Unit with -25°C to +25°C Temperature Range, Parallel Flow Condenser, and IP67 Waterproof Design for Electric Trucks
Specifications
Cooling Capacity(-18℃) :
1250W
Condenser Material :
Parallel Flow Condenser
Application Box Volume :
≤10 m³
Supply Ability :
50 sets per month
Lubricating Oil :
PAG68
Low Voltage Power :
DC-DC
Evaporator Material :
Inner grooved copper tube&aluminum Fin
Certification :
CE
Brand Name :
Yinhuasheng/OEM
Model Number :
EV300
Place of Origin :
China
MOQ :
1SET
Price :
Negotiable
Packaging Details :
Negotiable
Delivery Time :
Negotiable
Payment Terms :
TT
Description
EV300 Vehicle Refrigeration Unit -25℃-25℃ Temperature Range for Full Electric Truck
Product Description

Powered by the vehicle battery, our EV-300 unit is specially designed for NEV full electric trucks. This unit is widely used for reefer truck boxes up to 10m³ in size.

Yinhuasheng units are the preferential choice for customers seeking durability and reliability, combined with low operational costs and efficient handling.

Standard Features
  • Applicable for small and medium sized new energy vehicles
  • High grade (IP67) water-proof and insulation design, AC-DC interlock and four-in-one design
  • Ultra-slim fiberglass or aluminum alloy evaporator with high air flow
  • Fully enclosed electric compressor: high efficiency, eco-friendly, not affected by vehicle speed
  • Compressor integrated inside condenser unit for compact design
  • Multi-functional LCD controller with precise temperature control, full display, easy operation, fault codes and alarms
  • No interference between charging and unit operation, saving charging time and extending battery life
  • HP and LP switch safety protection
  • Standard AC220V standby for parking cooling
Technical Parameters
Unit Model EV-300
Applicable Temperature -25℃ ~ +25℃
Box Volume ≤10m³
Cooling Capacity 0℃: 2350 W
-18℃: 1250 W
Compressor Model DDH356
Lubricating Oil PAG 68
Evaporator Material Inner grooved copper tube
Evaporator Fans 1 PCS
Condenser Material Parallel flow condenser
Condenser Fans 1 PCS
High Voltage DC250V-DC450V
Low Voltage Power DC-DC
Control Voltage DC12V (9-16V)
Refrigerant R404a
Refrigerant Charge 0.8 KG
Box Temperature Adjustment Electronic digital display
Safety Protection High and low pressure switch
Defrosting Hot gas defrost automatically
Evaporator Weight 13 KG
Condenser Weight <63 KG
Evaporator Dimensions 780*580*210 mm
Condenser Dimensions 1280*510*300 mm
Drive Model Full electric driven
Support and Services

We provide comprehensive technical support and service for all our Vehicle Refrigeration Unit products. Our experts are available to assist with installation, operation, and maintenance questions, as well as troubleshooting any issues you may encounter.

We offer multiple support options including online, phone, email, and live chat support. Our knowledgeable staff provides quick responses and helpful advice.

All products come with a comprehensive warranty. We guarantee performance as expected and will repair or replace any defective parts free of charge.

For assistance with our Vehicle Refrigeration Unit products, please contact us directly.
