EV-600MB Mono-Block Refrigeration Unit with -25°C To +25°C Temperature Range and 5850W Cooling Capacity for NEV Trucks
EV-600MB Mono-Block Refrigeration Unit with -25°C To +25°C Temperature Range and 5850W Cooling Capacity for NEV Trucks
Specifications
Temperature Range :
-25°C To +25°C
Compressor Brand :
Highly
Outside Temperature :
30°C To 50 °C
Compressor Mode :
DTH356
Evaporator :
Inner grooved copper tube&aluminum Fin
Cooling Capacity(0℃) :
5850W
Application Box Volume :
≤22 m3
Compressor Displacement :
PAG 68
Brand Name :
Yinhuasheng/OEM
Model Number :
EV-600MB
Certification :
CE
Place of Origin :
China
MOQ :
1SET
Price :
Negotiable
Payment Terms :
TT/LC
Supply Ability :
1000 sets per month
Delivery Time :
Negotiable
Packaging Details :
Negotiable
Cooling Capacity(-18℃) :
3400W
Condenser :
Parallel Flow Condenser
Model :
EV-600MB
Description
Mono-Block Electric Refrigeration System for van EV-600MB
This Mono-block refrigeration unit is powered by the vehicle battery, specifically designed for NEV full electric trucks and widely used for reefer truck boxes up to 22m³. Yinhuasheng units are the preferred choice for customers seeking durability, reliability, low operational costs, and minimal handling charges.
Standard Features
  1. Applicable for small and medium sized new energy vehicles
  2. High grade (IP67) water-proof and insulation design, AC-DC interlock and four in one design
  3. Ultra-slim fiberglass evaporator or Al-alloy evaporator, with high air flow capacity
  4. Fully enclosed electric compressor: high efficiency, eco-friendly, not affected by vehicle speed
  5. Compressor integrated inside the condenser unit for compact design
  6. Multi-functional LCD controller with precise temperature control, full display, easy operation, fault codes and alarms
  7. No interference between charging and unit operation, saving charging time and extending battery life
  8. HP and LP switch safety protection
  9. Standard AC220V standby for parking cooling
Product Images
EV-600MB Mono-Block Refrigeration Unit with -25°C To +25°C Temperature Range and 5850W Cooling Capacity for NEV Trucks EV-600MB Mono-Block Refrigeration Unit with -25°C To +25°C Temperature Range and 5850W Cooling Capacity for NEV Trucks
Technical Specifications
Parameter Value
Unit Model EV-600MB
Applicable Temperature -25℃ ~ +25℃
Box Volume ≤22m³
Cooling Capacity (0℃) 5850 W
Cooling Capacity (-18℃) 3400 W
Compressor Model DTH356
Lubricating Oil PAG 68
Evaporator Material Inner grooved copper tube
Evaporator Fans 3 PCS
Condenser Material Parallel flow condenser
Condenser Fans 2 PCS
Refrigerant R404a
Refrigerant Charge 2.0KG
Box Temperature Adjustment Electronic digital display
Safety Protection High and low pressure switch
Defrosting Hot gas defrost automatically
Weight/Dimensions 1830*570*680mm (＜151KG)
Drive Model Full electric drive
