Ultra-Fast Cure Flexible UV Coating Glue Description

"Coat fast, flex forever." This ultra-fast cure flexible UV coating glue (3160) is a light yellow transparent, UV curing conformal coating specially formulated for ribbon cable, FFC (flexible flat cable) and wire harness insulation. It features ultra-fast curing speed, excellent flexibility and bending resistance, good adhesion to PE, PET, FFC and other plastic materials, and remains transparent after curing with reliable moisture-proof, insulating and aging-resistant performance.

Ultra-Fast Cure Flexible UV Coating Glue Datasheet

Product Details Description

Product Applications

• FFC (flexible flat cable) conformal coating and insulation
• Ribbon cable and color row parallel wire coating and protection
• Wire harness insulation for electronic assemblies
• Conformal coating of plastic materials and components
• PE and PET substrate coating applications
• Moisture-proof and insulating protection of flexible circuits
• Bending-resistant coating for repeatedly flexed parts
• Fast-cure coating for high-efficiency production lines

Precautions

• Surfaces must be clean, dry and free of oil, dust or release agents before coating.
• Apply a uniform coating thickness; avoid excess build-up around connectors and terminations.
• UV curing requires light to reach the coating; shadowed areas may need additional passes.
• Confirm adhesion and flexibility on the actual substrate before mass production.
• Apply in a well-ventilated area. Avoid contact with skin and eyes; wear protective gloves and safety goggles.
• In case of skin or eye contact, rinse immediately with plenty of clean water and seek medical advice if irritation persists.
• Store sealed at 8-28°C in a cool, dark and dry place away from direct sunlight and UV sources, and keep out of reach of children.

FAQ

Q1: What is this ultra-fast cure flexible UV coating glue mainly used for?

It is a UV curing coating glue for ribbon cable, FFC (flexible flat cable) and wire harness insulation, as well as conformal coating of plastic materials such as PE and PET.

Q2: How fast does it cure?

It features ultra-fast curing speed at 300 mJ/cm² of UV energy, enabling high-efficiency production lines.

Q3: Is the coating flexible after curing?

Yes. The cured coating offers excellent flexibility and bending resistance, making it suitable for FFC, ribbon cables and wires that require repeated flexing.

Q4: What materials does it adhere to?

It provides good adhesion to PE, PET, FFC and various other plastic materials commonly used in electronic assemblies.

Q5: What protection does the cured coating provide?

The coating remains transparent after curing while providing reliable moisture-proof, insulating and aging-resistant protection, with dielectric strength of 18 kV/mm.

Q6: What are the storage conditions and packaging?

Store sealed at 8-28°C in the original container, away from direct sunlight. Shelf life is 12 months, available in 250ml and 1kg packaging.
