UV Curing Security Glass Fixing Adhesive

3117 UV Curing Security Glass Fixing Adhesive is an amber transparent, fast-curing UV adhesive specially formulated for security glass fixing. It provides fast curing and excellent adhesion to glass, metal, plastic and painted surfaces, along with resistance to water immersion and boiling water and outstanding aging resistance.

Technical Specifications

Key Features

• Fast curing
• Excellent adhesion to glass, metal, plastic and painted surfaces
• Water immersion and boiling water resistant
• Excellent aging resistance
• Ideal for security glass fixing
• Reliable bonding and sealing of security glass assemblies

Applications

• Security glass fixing and bonding
• Bonding of glass and metal components in security devices
• Fixing of security glass panels and windows
• Bonding requiring water and boiling water resistance
• Applications requiring fast cure and aging resistance

Operation and Curing Guide

1. Surface preparation: clean the glass and bonding surfaces to remove oil, dust and contaminants for full adhesion.
2. Dispensing: apply the adhesive evenly to the glass fixing area.
3. Assembly: position and join the glass parts and remove any excess adhesive before curing.
4. UV curing: expose the adhesive to UV light at 800 mJ/cm² until fully cured.
5. Inspection: verify complete coverage and a firm, transparent bond.
6. Rework: gently separate bonded parts, clean the surfaces and re-apply the adhesive when repair is needed.

FAQ

Q1: What is the 3117 adhesive mainly used for?
3117 is a UV curing security glass fixing adhesive used for bonding and fixing security glass assemblies.

Q2: How fast does it cure?
3117 cures quickly under UV light at 800 mJ/cm² for efficient production.

Q3: What materials does it bond?
3117 offers excellent adhesion to glass, metal, plastic and painted surfaces.

Q4: Is it resistant to water?
Yes. 3117 is resistant to water immersion and boiling water, ensuring durable performance in humid or wet conditions.

Q5: What adhesion and hardness does it provide?
3117 achieves a 14N adhesion result in the 100 grid test with a Shore D 75 hardness and a glass transition temperature (Tg) of 80°C.

Q6: What are the storage conditions and packaging?
Store at 8-28°C in the original sealed container. Shelf life is 12 months. Available in 2kg packaging.
