UV Curing Crystal Bonding Adhesive

3013 UV Curing Crystal Bonding Adhesive is a light yellow transparent UV adhesive developed for crystal, glass and metal bonding. It offers strong versatility and high bonding strength, with good adhesion even on small bonding areas, and cures to a long-lasting bond that does not whiten or peel.

Technical Specifications

Key Features

• Strong versatility for crystal, glass and metal
• High bonding strength
• Good adhesion even on small bonding areas
• No whitening or peeling after curing
• Ideal for crystal-to-crystal bonding
• Reliable bonding of crystal, glass and metal parts

Applications

• Crystal and glass bonding
• Bonding of crystal crafts and decorative crystal
• Small-area bonding of crystal and metal parts
• Bonding of glass and metal components
• Applications requiring high strength and clarity

Operation and Curing Guide

1. Surface preparation: clean the crystal and bonding surfaces to remove oil, dust and contaminants.
2. Dispensing: apply a small amount of adhesive to the bonding area.
3. Assembly: position and join the parts, removing any excess adhesive before curing.
4. UV curing: expose the adhesive to UV light at 1500 mJ/cm² until fully cured.
5. Inspection: verify a strong, clear bond with no whitening.
6. Rework: gently separate bonded parts, clean the surfaces and re-apply the adhesive when repair is needed.

FAQ

Q1: What is the 3013 adhesive mainly used for?
3013 is a UV curing crystal bonding adhesive used for bonding crystal, glass and metal parts.

Q2: Is it strong enough for small bonding areas?
Yes. 3013 provides good adhesion even on small bonding areas, ensuring reliable bonds on small crystal parts.

Q3: Does it whiten or peel?
No. 3013 cures to a long-lasting bond that does not whiten or peel.

Q4: What materials does it bond?
3013 bonds crystal, glass and metal with high strength and strong versatility.

Q5: What strength does it provide?
3013 has a Shore D 78 hardness, a tensile strength of 20 MPa and a shear strength of 13 MPa.

Q6: What are the storage conditions and packaging?
Store at 8-28°C in the original sealed container. Shelf life is 12 months.
