Walker Fatigue and Durability Testing Machine
Walker Fatigue and Durability Testing Machine
Walker Fatigue and Durability Testing Machine
Walker Fatigue and Durability Testing Machine
Specifications
Brand Name :
Dongjun
Model Number :
DJ-26-14
Certification :
ISO9001
Place of Origin :
Dongguan, China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500pcs
Delivery Time :
15-25Work days
Packaging Details :
Wooden crate packaging
Equipment dimensions :
20000*1200*2000mm(L*D*H)
Maximum load :
300kg
Loading frequency :
0-20 times per minute
Speed :
1-50 times per minute
Loading cycles :
1-999999
Voltage :
220V 50HZ
Description
Walker Fatigue and Durability Testing Machine
Product Overview

This machine is designed for testing samples of wheeled walkers with 2 or more wheels. It is installed on a running belt with a speed not exceeding 3 km/h. The machine features electric cylinder + servo motor + PLC touch screen control, allowing users to set and display traveling speed, loading force, loading frequency, and loading cycles. The system automatically stops when the preset loading cycle is reached.

Technical Specifications
Parameter Item Specification
Control System PLC + Touch Screen + Program Control
Maximum Load 300KG
Loading Frequency Less than 1Hz, adjustable from 0 to 20 times per minute
Speed 1-50 times per minute, adjustable
Number of Loading Cycles Adjustable from 1 to 999,999
Equipment Dimensions 20000 × 1200 × 2000mm (L × D × H)
Voltage 220V 50HZ
Equipment Features
Walker Fatigue and Durability Testing Machine
  • Compliant with GB/T 14728.2-2024/ISO 11199-2:2021 standards
  • Control mode: PLC + touch screen + program control
  • Configurable driving speed, loading force, loading frequency, and loading cycles
  • Test method: Thickened belt + variable frequency motor mode (treadmill mode)
  • Simple operation without adjusting sample center distance
  • Sample directly fixed on treadmill frame
  • Performs dynamic pressure and static pressure tests
Walker Fatigue and Durability Testing Machine
  • 63-500mm electric cylinder + 750W servo motor + high-precision pressure sensor
  • Ensures minimal test data fluctuations and deviations
  • Provides accurate and reliable test results
Company Profile
Walker Fatigue and Durability Testing Machine
Packing and Transportation
Walker Fatigue and Durability Testing Machine Walker Fatigue and Durability Testing Machine
Frequently Asked Questions
How to install and use the product?

The product is shipped with English operating instructions and video. We will also provide an operation video with English narration to guide you through installation and usage. If you require face-to-face training, please notify us in advance.

How about the packing for machine, is it safely protected during transportation?

Our machines are packed in standard export wooden boxes to ensure complete protection during transportation. We have extensive experience delivering testing machines internationally via sea and air freight without any damage incidents.
