41x82 Hot Dipped Galvanized Double Spliced C Strut Channel with High Section Rigidity for Large Diameter Pipeline Support
41x82 Hot Dipped Galvanized Double Spliced C Strut Channel with High Section Rigidity for Large Diameter Pipeline Support
41x82 Hot Dipped Galvanized Double Spliced C Strut Channel with High Section Rigidity for Large Diameter Pipeline Support
41x82 Hot Dipped Galvanized Double Spliced C Strut Channel with High Section Rigidity for Large Diameter Pipeline Support
41x82 Hot Dipped Galvanized Double Spliced C Strut Channel with High Section Rigidity for Large Diameter Pipeline Support
41x82 Hot Dipped Galvanized Double Spliced C Strut Channel with High Section Rigidity for Large Diameter Pipeline Support
Specifications
Certification :
ISO9001
Service :
Custom Metal Fabrication Service
Supply Ability :
50000 pieces per day
Usage :
Construction, Electromechanical, Machinery
Surface treatment :
Galvanized Coated/Powder Coating
Payment Terms :
T/T, PayPal, Xtransfer
Length :
1m-12m or Customer's Requirments
Delivery Time :
Delivery within 15-30 days
Processing performance :
Cutting, Decoiling, Punching, Welding, Bending
Thickness :
1.5mm / 2.0mm / 2.5mm (Customizable)
Price :
$ 0.9-2.4
Packaging Details :
Wooden frame or cardboard box packaging, customizable
Technique :
Cold Bending/Roll Forming
Product Name :
Strut Channel / C Channel / Unistrut Channel
Material :
Metal
Application :
Building operations
MOQ :
1000 pieces
Suitable for :
Lightweight supports, photovoltaic supports, keels, roof trusses, equipment frames, guardrails, bridge racks, etc
Place of Origin :
Hebei, China
Model Number :
41×82 Double Spliced Metal Strut Channel
Alloy Or Not :
Non-Alloy
Feature :
Corrosion Resistant, High Strength, Easy Installation, Modular Design
Color :
Silver Zinc / Stainless Steel Natural Color
Description
41×82 Hot Dipped Galvanized Double Spliced C Strut Channel for Heavy-Duty MEP Support Systems

Product Overview

41×82 hot dipped galvanized double spliced C strut channel is a heavy-duty modular structural profile, specially developed for building MEP (mechanical, electrical, plumbing) integrated hanging and support systems. It is formed by two standard 41×41 single C channels spliced side by side, adopting high-quality Q235 carbon steel and professional cold roll forming technology.
The whole profile is treated with hot-dip galvanizing process with a zinc layer thickness over 85μm, featuring uniform coating, compact texture and excellent long-term anti-rust and anti-corrosion performance. It maintains stable structural performance in humid, acidic and alkaline environments, effectively extending the service life of pipeline and equipment support systems compared with ordinary steel profiles.
Benefiting from double-spliced reinforced structure, this 41×82 strut channel delivers ultra-high section rigidity, outstanding bending and torsion resistance, which can evenly bear heavy loads of large-diameter pipelines, HVAC equipment, cable trays and electromechanical facilities, avoiding structural deformation caused by concentrated stress. Pre-punched standard elongated slotted holes support tool-free modular assembly, perfectly matched with standard spring nuts and connecting fittings, greatly improving on-site construction efficiency.
Parameter Category
Specific Information
Product Name
41×82 Double Spliced Hot Dipped Galvanized C Strut Channel
Alternative Name
Heavy-duty MEP support channel, double combined C bracket channel
Raw Material
Q235 Carbon Steel; Optional 304/316 Stainless Steel
Surface Treatment
Hot Dipped Galvanizing(HDG, zinc layer ≥85μm), Pre-galvanized, Electro-galvanized
Surface Color
Silver metallic zinc tone
Cross Section Size
41×82mm (double 41×41 splicing structure), customized non-standard sizes available
Plate Thickness
1.5mm / 2.0mm / 2.5mm, custom thickness supportable
Standard Length
1m / 2m / 3m / 6m, custom cutting length available
Hole Type
Solid plain type, standard slotted long holes, custom drilling layout
Load Grade
Medium / Heavy / Extra Heavy Load, customized load-bearing design
Core Advantages
Reinforced double-spliced structure, high rigidity, superior corrosion resistance, modular quick installation, strong load capacity
Application Scope
MEP pipeline hanging systems, HVAC supports, fire protection piping, large-span cable tray brackets, industrial equipment fixing, building structural supports
Certification
ISO9001, RoHS Compliance
Custom Service
Full OEM & ODM support, customizable size, thickness, hole pattern and surface finish
Packaging
Steel strapping + export wooden pallet, customized packaging acceptable

Product Features

This 41×82 double spliced C strut channel adopts reinforced double-channel composite structure, effectively solving the load limitation of single C channel. It provides stable and reliable heavy-load support for large-span and heavy-duty electromechanical pipeline projects. The integral hot-dip galvanized layer ensures long-term anti-corrosion performance for outdoor and humid industrial environments.
Standard modular design realizes fast bolt assembly without on-site welding, greatly improving construction efficiency and reducing project cost. With complete specifications and flexible customization, it is widely applicable to new building construction, old building renovation, industrial plant electromechanical installation and municipal supporting projects, serving as the preferred heavy-duty supporting profile for MEP systems.
41x82 Hot Dipped Galvanized Double Spliced C Strut Channel with High Section Rigidity for Large Diameter Pipeline Support

FAQ

Q1: Are you a professional manufacturer or trading company?
We are a professional steel strut channel factory with complete automated production and testing equipment. All products are fully self-produced, with stable quality and factory direct sales price. Factory inspection is warmly welcomed.

Q2: What is your production lead time?
Standard stock orders can be delivered quickly. Bulk orders are normally completed within 30 working days after deposit confirmation. Partial shipment is acceptable for large projects.

Q3: Can you provide customized design service?
Yes. Our professional engineering team can provide exclusive structural design, processing drawings and installation solutions according to customer project requirements, supporting one-stop customized service.

Q4: What are your payment terms?
30% deposit in advance, 70% balance settled before shipment.

Q5: How do you guarantee product quality?
We implement full-process quality control: standardized design risk prediction, strict incoming raw material inspection, automated precision production and multi-process finished product inspection, to ensure all products meet international quality standards.
