Aluminum Alloy Solar Panel Brackets Quick Installation 41×41 Strut Channel
Aluminum Alloy Solar Panel Brackets Quick Installation 41×41 Strut Channel
Aluminum Alloy Solar Panel Brackets Quick Installation 41×41 Strut Channel
Aluminum Alloy Solar Panel Brackets Quick Installation 41×41 Strut Channel
Specifications
Delivery Time :
15-20days from the date of Payment
MOQ :
500 pcs
Size :
Standard size
Price :
$0.8-$3.5/m
Brand Name :
Jiucan Metal
Compatible Profile :
41×41 Strut Channel
Place of Origin :
Hebei,China
Material :
Q195/Q235/Steel
Sample :
Free
Certification :
ISO9001
Product name :
PV Panel Support
Process Service :
Welding , Bending
Packaging Details :
50 Or 100PCS Are Packed In Steel Pallet , And Fasten With Steel Strips
Tolerance :
±3%
Supply Ability :
50 to 80+ tons/day
Payment Terms :
T/T,T/T
Thickness :
0.8-3mm/Customized
Description

Aluminum Alloy Solar Panel Bracket Quick Installation

Introduction

This aluminum alloy solar panel bracket is a lightweight, high-efficiency mounting system designed for quick and easy photovoltaic installation. Made of AL6005-T5 aluminum alloy with anodized surface treatment, it combines light weight, high strength and excellent corrosion resistance. The bracket’s modular structure and pre-positioned holes enable tool-friendly fast assembly, greatly shortening construction cycles and reducing labor costs. It is widely used in residential rooftop solar, lightweight commercial PV systems and quick-installation solar projects. The aluminum material effectively reduces roof load while ensuring strong support capacity. Anti-corrosion surface ensures long service life with almost no maintenance. Each component is precision extruded and processed for high fitting accuracy and stable connection. Compliant with international PV standards, it provides a fast, safe and durable solution for modern solar panel installation.

Features

This solar bracket uses lightweight AL6005-T5 aluminum alloy for high strength and low weight. Anodized surface provides excellent anti-corrosion, anti-UV and anti-aging performance. Modular plug-and-play design enables ultra-fast installation, improving project efficiency. Stable structure ensures strong wind resistance and safety. Lightweight design reduces roof load and transportation cost. Rust-free and maintenance-free performance extends service life to over 25 years. High compatibility fits most solar panel sizes and mounting layouts. Eco-friendly and recyclable material supports green energy development. It provides efficient, convenient and reliable support for fast-installation solar projects.

Specification

Parameter Specification Details
Product Name Solar Mounting Bracket, PV Panel Support, Solar Racking Structure
Material AL6005-T5 Aluminum Alloy; Q235B Hot Dip Galvanized Steel
Surface Treatment Anodized (Aluminum); Hot Dip Galvanized (Steel); Pre-galvanized
Structure Type Fixed, Adjustable, Roof Mount, Ground Mount, Universal Type
Suitable Panel 150W–700W Monocrystalline & Polycrystalline PV Panels
Adjustable Angle 0°–60° (adjustable type); Fixed (custom angle)
Wind Load Resistance Up to 60m/s (130mph)
Snow Load Capacity 1.2–2.0 kN/㎡
Panel Orientation Portrait / Landscape
Installation Type Bolt Fastening, Modular Assembly, No Welding
Application Residential Rooftop, Commercial Roof, Solar Farm, Ground PV Station
Working Temperature -40℃ ~ +120℃
Service Life Aluminum: 25–30 years; Galvanized Steel: 20–25 years
Certification ISO9001, CE, TUV, SGS Test Report Available
Standard Length Customizable according to panel size
Thickness Aluminum: 1.8–3.0mm; Steel: 2.0–4.0mm
MOQ 100 sets / Small trial order acceptable
OEM & ODM Size, hole, color, logo, packaging all customizable
Packing Carton + Pallet; Custom packaging support
Supply Ability Mass production, factory wholesale, fast delivery



Aluminum Alloy Solar Panel Brackets Quick Installation 41×41 Strut Channel


FAQ

Q: Do you provide free sample?
A: Yes, but please note the transportation charge will be paid on your side.

Q: What kind of materail you can offer?
A: We can offer you GALVANIZED STEEL, STAINLESS STEEL, ALUMINUM, CABLE TRAY.
Q: What kind of standard you are following?
A: We are producing following by GB/T19001-2008, ISO9001:2008, SGS, MA...
Q: Could you change the size for the customer?
A: Yes, depends on your special demands.
Q: How many days delivery the order?
A: Normally 20 days after deposit or L/C, depends your request.
