Precision 4-Tank Ultrasonic Cleaner - High-Pressure Spraying for Blind Hole & Gap Cleaning
Precision 4-Tank Ultrasonic Cleaner - High-Pressure Spraying for Blind Hole & Gap Cleaning
Specifications
Brand Name :
Jietai
Model Number :
JTM-4024FRSD
Certification :
CE, FCC, ROHS, etc.
Place of Origin :
Dongguan, Guangdong
MOQ :
1
Price :
￥34500
Payment Terms :
T/T
Supply Ability :
One unit. It will take 30 to 60 days.
Delivery Time :
30-60work days
Packaging Details :
Packaging: Wooden case, wooden frame, stretch film.Dimensions:500*300*300mm
Spray Function :
Standard
Cleaning frequency :
28KHZ/40KHZ
Overall Dimensions :
500*300*300mm
tank capacity :
45L
Model :
JTM-4024FRSD
Power :
0-600W*2
Heating Power :
1.5KW
Filtration Circulation :
Standard
Drying Temperature (℃) :
Normal - 150℃
Time Control :
1-99MIN
Cleaning Temperature Control :
Normal - 95℃
Description

4-Tank Ultrasonic Cleaner: Tailor-Made "Four-Dimensional Cleaning" Closed-Loop Solution for High-Demand Scenarios


4-Stage Precision Cleaning: Tailored Solutions for High-Demand Industries


Precision components across different industries face vastly distinct cleaning pain points — ionic residues on electronic components, sterility requirements for medical devices, heavy oil contamination on auto parts, scratch-free cleaning for optical lenses, etc. Jietai 4-Tank Series (Cleaning & Filtration + Rinsing + Spraying + Drying) adopts the "four-dimensional cleaning" logic to address the core pain points of each industry in a targeted manner, making the cleaning process more precise, efficient and compliant.

Customized Solutions for Specific Industries


Electronics/Semiconductor Industry


Pain Points: Residual solder slag on PCB/FPC circuit boards, stains in the gaps of chip pins, and excessive ionic contamination.

Solutions:

  • Cleaning Tank: 60-100kHz high-frequency ultrasonic waves with low power density (0.1-0.3W/cm²) to avoid damaging precision circuits.
  • Rinsing Tank: Rinsing with 18MΩ ultrapure water to remove ionic residues, complying with the cleaning standards of the electronics industry.
  • Spraying Tank: Low-pressure directional spraying at 0.3-0.5MPa to rinse off solder slag in the gaps of pins.
  • Drying Tank: Low-temperature hot air drying at 40-60℃ to prevent oxidation and discoloration of components, suitable for cleaning semiconductor packages and electronic components.

Medical/Dental Industry


Pain Points: Residual blood and tissue on surgical instruments, stains inside dental handpieces, and the need to meet sterility standards.

Solutions:

  • Cleaning Tank: Made of antibacterial 316L stainless steel with detachable cleaning baskets. 28-40kHz ultrasonic waves combined with 80℃ high-temperature cleaning to powerfully remove organic residues.
  • Rinsing Tank: Rinsing with circulating sterile water, equipped with an ultraviolet disinfection module to ensure the cleanliness of the rinsing water.
  • Spraying Tank: High-pressure spraying at 0.4-0.6MPa to rinse hidden areas such as instrument joints and alveoli.
  • Drying Tank: High-temperature hot air drying and sterilization at 100-120℃, meeting medical sterility requirements, suitable for cleaning surgical instruments, dental handpieces and medical accessories.
