Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Model NO. :
CLW5122K8GMR
Wrecker Type :
One-Towing-One, One-Towing-Two
Chassis Brand :
Dongfeng, , HOWO, Foton, JAC, etc.
Production Capacity :
500unit Per Month
Steering :
LHD, Rhd, Left Hand Drive, Right Hand Drive
Max Lifting Weight :
4tons; 5tons; 6tons
Hydraulic Systemht :
Famous International Brand
Bearing Capacity :
Medium
Cabin :
2~3 Personn with A/C
MOQ :
1
Price :
15000-35000 per unit
Towing Tonnage :
4ton
Truck Overall Size :
7280*2350*2400mm
Transmission Type :
Manual
Transport Package :
Bulk, RO-RO, Container
Origin :
Suizhou, China
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Name :
Recovery Tow Truck
HS Code :
8705909990
Emission Standard :
Euro 2
Engine :
130HP
Wheel Base :
3815mm
Condition :
New
Specification :
4t, 4tons, 4ton, 4T, 5t, 5tons, 5ton, 5T, 8tons
Winch Rope :
25m, 25meters
Trademark :
CLW
Fuel :
Diesel
Description
Factory Supplier 8tons Recovery Truck Body Wrecker Towing Car

Product Description:
1. Purpose of 6ton flatbed tow truc: wrecker/recovery truck/towing truck is used for towing broken cars,vehicle on road.With increasing ownership of private cars,wreckers are now widly used by government organization or towing company.
2. Optional brand of 6ton flatbed tow truc:howo,Dongfeng,JAC,JMC,Foton,Shacman...
3. Spare parts of 6ton flatbed tow truc: Italy brand multi-way valve and balance valve; Gernamy Roxroth technology hydraulic cylinder and joint; imported sealing element; strengthed checked plate
4. Capacity range of 6ton flatbed tow truc:3ton, 4ton, 5ton, 6ton, 8ton, 12ton, 16ton, 20ton, 25ton, 31ton, 40ton, 50ton
5. The customers can choose to install the crane.

General Technical Parameters
Overall Dimension9440x2480x2760 (mm)
Gross Vehicle Weight12495kg
Curb Weight8000kg
Chassis Specification









Chassis Parameters

Chassis BrandI-SUZU
CabinSingle row, Left Hand Driving



Engine

Model4HK1-TC51, 4 Cylinders
Power190HP
Emission StandardEURO V
Displacement4.5L
Fuel TypeDiesel
Gearbox6 Forward & 1 Reverse Gear
Front and Rear Axle Load4T/7T
Wheel Base4700(mm)
Overhang( Front/Rear)1015/2450(mm)
Angle(Approach/departure)24/9(°)
Brake SystemAir Brake
Steering GearPower Assistant
Tire235/75R17.5, 6 Pieces with 1 Spare Tire
Maximum Speed110(km/h)
Superstructure



Flatbed

Dimensions6200x2450 (mm)
Max. Loading Weight6000(kg)
Operating Stroke3300 (mm)
Min. Angle of Slope8(°)
Platform Height from the Ground1070(mm)


Winch

Quantity1pc
Winch Rating Pulling Capacity10000 (kg)
Length of Steel Cable25 (m)



Hoisting Organ

Rating Under-Pulling Capacity6000 (kg)
Rating Under-Hoisting Capacity2000 (kg)
Fully Extended Max Under-Hoisting Capacity1600 (kg)
Max Under-Hoist Useful Length1640 (mm)


Remarks

1. Equiped with One Set of Auxiliary Wheels
2. Bandages 4pcs
3. Yellow Warning Lamp 1pc
4. Double Side Hydraulic Operation
5. Can Tow 2 Cars
