Specifications
Place of Origin :
CHINA
Brand Name :
CLW
MOQ :
1
Price :
15000-35000 per unit
Model NO. :
CLW5076BGQ
Emission Standard :
Euro 3
Transmission Type :
Manual
Towing Tonnage :
4ton
Fuel :
Diesel
Bearing Capacity :
Light
Brand :
Dongfeng
Condition :
New
Steering :
LHD, Rhd, Left Hand Drive, Right Hand Drive
Engine :
102HP
Wrecker Type :
One-Towing-One, One-Towing-Two
Max Lifting Weight :
3tons; 4tons; 5tons
Delivery Time :
30 Days
Hydraulic System :
Famous International Brand
Chassis Brand :
Dongfeng, HOWO, Foton, JAC, etc.
Cabin :
2~3 Personn with A/C
Wheel Base :
3308mm
Truck Overall Size :
5997*2300*2220mm
Max Towing Weight :
3tons; 4tons; 5tons
Winch Rope :
25m, 25meters
Transport Package :
Bulk, RO-RO, Container
Specification :
3T, 3ton, 3tons, 4t, 4tons, 4ton, 7tons
Trademark :
CLW
Origin :
Suizhou, China
HS Code :
8705909990
Production Capacity :
500unit Per Month
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Name :
Wrecker Truck
Description

Dongfeng Light Duty 3-7ton Road Cars Rescue Towing Trucks 3-7t Platform Tow Wrecker

Product Description

1) 5Tons Wrecker Truck for Towing Broken Cars or Equipments.

2) Dongfeng Brand Chassis for Euro 2 or Euro 3 Emission

3) Spare parts of 5tons wrecker tow truck:

  • Italy brand multi-way valve and balance valve;
  • Gernamy Roxroth technology hydraulic cylinder and joint;
  • International Brand Sealing elements;
  • Strengthed Checked platform.

Product Specification

General Technical Specification
Overall Dimension 5997x2300x2220(mm)
Gross Vehicle Weight 4495 (Kg)
Curb Weight 3600(Kg)
Chassis Specification
Chassis Brand Dongfeng
Drive model 4*2
Cabin Single, Left Hand Drive




Engine

 Model 4-stroke direct injection, 4-cylinder in-line with water cooling, turbo-charging and inter-cooling
Power 75KW/102HP
Emission standard EURO2 or 3
Displacement 3707(ml)
Fuel type Diesel
Gearbox 5 Forwards & 1 Reverse, Power steering, hydraulic steering with power assistance
Brake System Pneumatic(Air break/exhaust brake)
Wheel Base 3308(mm)
Front/Rear Axle Loading 3000/3500(Kg)
Approach/Departure Angle 24/12(°)
Tire 7.00R16, 6pcs + 1 spare tire
Max Driving Speed 105(km/h)
Superstructure Specification




Platform Organ

 Dimension 4200*2320(mm)
Rear manual flip board length 1200(mm)
Material Q235 carbon steel
Max Loading capacity 3000(kg)



Winch

 Quantity 1
Winch rating towing capacity 4000(kg)
Length of steel rope 25(m)
Speed of winch 3.23~8 (m/min)
Other parts Auxiliary wheels, alarm light, hooks, 4 bundling belt, automatic sliding plate, etc.
Options Caution light, air condition,inlet valve.
