Specifications
Place of Origin :
CHINA
Brand Name :
CLW
MOQ :
1
Price :
15000-35000 per unit
Name :
Wrecker Truck
Model NO. :
CLW1027CVA2
Emission Standard :
Euro 2
Transmission Type :
Manual
Towing Tonnage :
5T
Fuel :
Diesel
Bearing Capacity :
Light
Brand :
JAC
Condition :
New
Type :
Flatbed Type
Control Type :
Hydraulic Handle Control
Flatbed Length :
5500mm
Flatbed Height :
1070mm
Max Lifting Weight :
1430kg
Max Towing Arm Length :
1640mm
Flatbed Loading Weight :
3000kg
Purpose :
Broken Vehicle Rescue
Landing Ways :
Fulllanded or Half Landed
Control Position :
Both Side of Truck Back
Flatbed Width :
2200mm
Tilting Angle :
0 / 8
Max Towing Weight :
6000kg
Towing Arm Length :
1640mm
Transport Package :
Bulk, RO-RO, Container
Specification :
3Ton ~ 5Ton
Trademark :
CLW
Origin :
Suizhou, China
HS Code :
8705909090
Production Capacity :
500unit Per Month
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Description
JAC 5ton Breakdown Recovery Flatbed Rescue Tow Truck
Product Description

1) 5Tons Wrecker Truck for Towing Broken Cars or Equipments.

2) JAC Brand Chassis for Euro 2 or Euro 3 Emission

3) Spare parts of 5tons wrecker tow truck:

  • Italy brand multi-way valve and balance valve;
  • Gernamy Roxroth technology hydraulic cylinder and joint;
  • International Brand Sealing elements;
  • Strengthed Checked platform.
Product Specification
General Technical Specification
Overall Dimension 7500x2300x2460(mm)
Gross Vehicle Weight 7300 (Kg)
Curb Weight 3800 (Kg)
Chassis Specification
Chassis Brand JAC
Drive model 4*2
Cabin Single, Left Hand Drive



Engine

 Model 4-stroke direct injection, 4-cylinder in-line with water cooling, turbo-charging and inter-cooling
Power 72KW/98HP
Emission standard EURO 2
Displacement 2771(ml)
Fuel type Diesel
Gearbox 5 Forwards & 1 Reverse, Power steering, hydraulic steering with power assistance
Brake System Pneumatic(Air break/exhaust brake)
Wheel Base 3815(mm)
Front/Rear Axle Loading 2500/4800(Kg)
Approach/Departure Angle 24/12(°)
Tire 7.00R16, 6pcs + 1 spare tire
Max Driving Speed 98(km/h)
Superstructure Specification



Platform Organ

 Dimension 5500*2300(mm)
Rear manual flip board length 800(mm)
Material Q235 carbon steel
Max Loading capacity 4000(kg)



Winch

 Quantity 1
Winch rating towing capacity 4000(kg)
Length of steel rope 25(m)
Speed of winch 3.23~8 (m/min)


Hoisting Organ

 Rating Under-Pulling Capacity 5000(kg)
Rating Under-Hoisting Capacity 2000(kg)
Other parts Auxiliary wheels, alarm light, hooks, 4 bundling belt, automatic sliding plate, etc.
Options Caution light, air condition,inlet valve.
