Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Transmission Type :
Manual
MOQ :
1
Price :
15000-35000 per unit
Condition :
New
Name :
Breakdown Recovery Truck
Hydraulic Tailgate :
1200 mm
First Flatbed Dimension :
4200X2320mm
Specification :
8500x2480x2760 mm
Engine :
120HP, Diesel
Origin :
Suizhou, China
Emission Standard :
Euro 2
Winch Rating Pulling Capacityt :
5000kg
Chassis Brand :
Dongfeng, HOWO, Foton, JAC, etc.
Delivery Time :
30 Days
Wire Rope :
25 Meters
Gearbox :
6forward & 1 Reverse
Model NO. :
CLW5304VC1144
Tire :
9.00r20
Transport Package :
Bulk, RO-RO, Container
Bearing Capacity :
Medium
Hydraulic Systemht :
Chinese/ International Brand
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Towing Tonnage :
8ton 9ton 10ton
Brand :
FAW
Trademark :
CLW
Wheel Base :
4500 mm
HS Code :
8705909990
Production Capacity :
500unit Per Month
Fuel :
Diesel
Max. Loading Weight :
5000kg
Description

FAW 8ton 9ton 10ton Breakdown Recovery Flatbed Rescue Wrecker Towing Truck

Product Description:

Purpose of flatbed tow truck: wrecker/recovery truck/towing truck is used for towing broken cars,vehicle on road.With increasing ownership of private cars,wreckers are now widly used by government organization or towing company.

Optional brand of flatbed tow truc:howo,Dongfeng, ,JAC,JMC,Foton,Shacman.

Spare parts of flatbed tow truc: Italy brand multi-way valve and balance valve; Gernamy Roxroth technology hydraulic cylinder and joint; imported sealing element; strengthed checked plate

Capacity range of flatbed tow truc:3ton, 4ton, 5ton, 6ton, 8ton, 12ton, 16ton, 20ton, 25ton, 31ton, 40ton, 50ton

The customers can choose to install the crane.

General Technical Parameters
Overall Dimension 5995x2300x2200(mm)
Gross Vehicle Weight 4495kg
Curb Weight 3700kg
Chassis Specification

Chassis Parameters

 Chassis Brand FAW
Cabin Single, Left Hand Driving

Engine

 Model 6 Cylinders
Power 180HP
Emission Standard EURO II
Fuel Type Diesel
Gearbox 6 Forward & 1 Reverse Gear
Front and Rear Axle Load 4.5T/9T
Wheel Base 4200(mm)
Overhang( Front/Rear) 1015/2450(mm)
Angle(Approach/departure) 24/16(°)
Brake System oil brake
Steering Gear Power Assistant
Tire 7.00R16, 6 Pieces with 1 Spare Tire
Maximum Speed 90 (km/h)
Superstructure

Flatbed

 Dimensions 4200x2320 (mm)
Max. Loading Weight 4000(kg)
Operating Stroke 2700 (mm)
Min. Angle of Slope 8(°)
Platform Height from the Ground 1070(mm)

Winch

 Quantity 1pc
Winch Rating Pulling Capacity 4000 (kg)
Length of Steel Cable 25 (m)

Hoisting Organ

 Rating Under-Pulling Capacity 6000 (kg)
Rating Under-Hoisting Capacity 2000 (kg)
Fully Extended Max Under-Hoisting Capacity 1600 (kg)
Max Under-Hoist Useful Length 1640 (mm)

Remarks
  • Equiped with One Set of Auxiliary Wheels
  • Bandages 4pcs
  • Yellow Warning Lamp 1pc
  • Double Side Hydraulic Operation
  • Can Tow 2 Cars
