Jmc 3tons 4tons New Light Duty Wrecker Recovery Tow Truck
Jmc 3tons 4tons New Light Duty Wrecker Recovery Tow Truck
Jmc 3tons 4tons New Light Duty Wrecker Recovery Tow Truck
Jmc 3tons 4tons New Light Duty Wrecker Recovery Tow Truck
Jmc 3tons 4tons New Light Duty Wrecker Recovery Tow Truck
Jmc 3tons 4tons New Light Duty Wrecker Recovery Tow Truck
Jmc 3tons 4tons New Light Duty Wrecker Recovery Tow Truck
Jmc 3tons 4tons New Light Duty Wrecker Recovery Tow Truck
Jmc 3tons 4tons New Light Duty Wrecker Recovery Tow Truck
Jmc 3tons 4tons New Light Duty Wrecker Recovery Tow Truck
Specifications
Emission Standard :
Euro 4
Transmission Type :
Manual
Towing Tonnage :
3T
Fuel :
Diesel
Bearing Capacity :
Light
Brand :
JMC
Condition :
New
Hydraulic Systemht :
Chinese/ International Brand
Chassis Brand :
Dongfeng, HOWO, Foton, JAC, etc.
Delivery Time :
30 Days
Drive :
LHD or Rhd
Engine for Option :
Cum-mins, Weichai, Yuchai
Loading Weight of Flatbed :
3 Ton/5 Ton / 8 Ton
Tow Type :
One Towing Tow
Type :
Half Landing or Full Landing
Transport Package :
Bulk, RO-RO, Container
Specification :
3ton /5ton /8ton
Trademark :
CLW
Origin :
Suizhou, China
HS Code :
8705909090
Production Capacity :
500unit Per Month
Place of Origin :
CHINA
Brand Name :
CLW
Name :
Wrecker Truck
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
MOQ :
1
Price :
15000-35000 per unit
Description
Jmc 3tons 4tons New Light Duty Wrecker Recovery Tow Truck
Product Description:

1. Purpose of flatbed tow truck: wrecker/recovery truck/towing truck is used for towing broken cars,vehicle on road.With increasing ownership of private cars,wreckers are now widly used by government organization or towing company.

2. Optional brand of flatbed tow truc:howo,Dongfen,JAC,JMC,Foton,Shacman.

3. Spare parts of flatbed tow truc: Italy brand multi-way valve and balance valve; Gernamy Roxroth technology hydraulic cylinder and joint; imported sealing element; strengthed checked plate

4. Capacity range of flatbed tow truc:3ton, 4ton, 5ton, 6ton, 8ton, 12ton, 16ton, 20ton, 25ton, 31ton, 40ton, 50ton

5. The customers can choose to install the crane.

JMC brand 4x2 hydraulic winch 4 ton towing car flat bed wrecker truck with wheel lift ( half landing or full landing)







Basic information

 Gross Vehicle Weight (kg) 8210
Curb Weight (kg) 4870
Rated Payload(kg) 3340
Overall Dimension(mm) 7440x2400x2400
Axle No. 2
Cab Allowed Persons 3
Wheelbase (mm) 3815
F/R Suspension(mm) 1155/2470
Max Speed(km/h) 100
Appr/Dep Angle(º) 12/20
Air condition YES





Chassis Specifications

 Chassis Model JX1083TK25
Drive Type 4x2
Axle Load(kg) 3310/4965
Tyre Spec. 7.50R16
Tyre No. 6+ 1 spare
Leaf Spring No. 8/7+7
Front/Rear Track (mm) 1680/1640
Service brake type Compressed air brake


Parking brake type

 Spring energy, compressed air operating
on rear wheels









Superstructure of upper platform


Platform material

 5mm stamping steel plate or
3mm punching steel plate can be choosed
Platform size (L X W mm) 5600 x 2300
Platform max lifting capacity (kg) 3500

Platform landing gradient Angle(º) <= 11

Hydraulic capstan winch- steel string length (m) 21 meters , or 30 meters can be choosed

Hydraulic capstain winch- steel string tension can afford 4 tons

Rear towing Max afford (kg) 3000kg
Auxiliary wheel 1 set







Engine & Transmission specifications

 Engine Model JX4D30A5H
Engine Brand JMC automobile Co., Ltd
Fuel type Diesel
Displacement (ml) / Power 2892 / 112kw (152HP)


Engine Type

 Turbocharged inter-cooled, 4 cylinder
in-line, water colling.
Emission Standard Euro V or III, IV can be selected
Rated speed 2800rpm
Max Torque 382N.m
Max torque(N.m/rpm) 1800-2800rpm
Driving type Manual
No of transmission gears 6 Forward, 1 Reverse


Remark

 1. With power assisted steering, auxiliary wheels, emergency rotation
lamp, spare tyre, hydrlic telescopic jack, wheel brace etc tools.
