Remote Control RC Full Landing Flatbed Low Angle Wrecker Tow Truck 4T 5T for road rescue
Remote Control RC Full Landing Flatbed Low Angle Wrecker Tow Truck 4T 5T for road rescue
Remote Control RC Full Landing Flatbed Low Angle Wrecker Tow Truck 4T 5T for road rescue
Remote Control RC Full Landing Flatbed Low Angle Wrecker Tow Truck 4T 5T for road rescue
Remote Control RC Full Landing Flatbed Low Angle Wrecker Tow Truck 4T 5T for road rescue
Remote Control RC Full Landing Flatbed Low Angle Wrecker Tow Truck 4T 5T for road rescue
Remote Control RC Full Landing Flatbed Low Angle Wrecker Tow Truck 4T 5T for road rescue
Remote Control RC Full Landing Flatbed Low Angle Wrecker Tow Truck 4T 5T for road rescue
Remote Control RC Full Landing Flatbed Low Angle Wrecker Tow Truck 4T 5T for road rescue
Remote Control RC Full Landing Flatbed Low Angle Wrecker Tow Truck 4T 5T for road rescue
Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Truck Overall Size :
7280*2350*2400mm
Emission Standard :
Euro 4
HS Code :
8705909990
Condition :
New
Engine :
98HP
Max Lifting Weight :
4tons; 5tons; 6tons
Model NO. :
CLW5076BGV
Cabin :
2~3 Personn with A/C
Chassis Brand :
Dongfeng, HOWO, Foton, JAC, etc.
Bearing Capacity :
Light
Wrecker Type :
One-Towing-One, One-Towing-Two
Winch Rope :
25m, 25meters
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Specification :
4T, 4ton, 4tons, 4t, 5tons, 5ton, 10tons
Origin :
Suizhou, China
Production Capacity :
500unit Per Month
Towing Tonnage :
4ton
Fuel :
Diesel
Steering :
LHD, Rhd, Left Hand Drive, Right Hand Drive
Transport Package :
Bulk, RO-RO, Container
Name :
Wrecker Truck
MOQ :
1
Price :
15000-35000 per unit
Transmission Type :
Manual
Hydraulic Systemht :
Famous International Brand
Trademark :
CLW
Wheel Base :
3815mm
Description

4t 5T Remote Control RC Full Landing Flatbed Low Angle Wrecker Towing truck road rescue tow Truck

Product Description
  • 5Tons Wrecker Truck for Towing Broken Cars or Equipments.
  • Dongfeng Brand Chassis for Euro 2 or Euro 3 Emission
  • Spare parts of 5tons wrecker tow truck:
    • Italy brand multi-way valve and balance valve;
    • Gernamy Roxroth technology hydraulic cylinder and joint;
    • International Brand Sealing elements;
    • Strengthed Checked platform.
Product Specification
General Technical Specification
Overall Dimension 7500x2300x2460(mm)
Gross Vehicle Weight 7300 (Kg)
Curb Weight 3800 (Kg)
Chassis Specification
Chassis Brand I-suzu
Drive model 4*2
Cabin Single, Left Hand Drive

Engine

 Model 4-stroke direct injection, 4-cylinder in-line with water cooling, turbo-charging and inter-cooling
Power 72KW/98HP
Emission standard EURO 4
Displacement 2771(ml)
Fuel type Diesel
Gearbox 5 Forwards & 1 Reverse, Power steering, hydraulic steering with power assistance
Brake System Pneumatic(Air break/exhaust brake)
Wheel Base 3815(mm)
Front/Rear Axle Loading 2500/4800(Kg)
Approach/Departure Angle 24/12(°)
Tire 7.00R16, 6pcs + 1 spare tire
Max Driving Speed 98(km/h)
Superstructure Specification

Platform Organ

 Dimension 5500*2300(mm)
Rear manual flip board length 800(mm)
Material Q235 carbon steel
Max Loading capacity 4000(kg)

Winch

 Quantity 1
Winch rating towing capacity 4000(kg)
Length of steel rope 25(m)
Speed of winch 3.23~8 (m/min)

Hoisting Organ

 Rating Under-Pulling Capacity 5000(kg)
Rating Under-Hoisting Capacity 2000(kg)
Other parts Auxiliary wheels, alarm light, hooks, 4 bundling belt, automatic sliding plate, etc.
Options Caution light, air condition,inlet valve.
