Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Trademark :
CLW
Brand :
JMC
Chassis Brand :
Dongfeng, HOWO, Foton, JAC, etc.
Hydraulic Systemht :
Chinese / International Brand
MOQ :
1
Price :
15000-35000 per unit
Specification :
3ton /5ton /8ton
Delivery Time :
30 Days
Origin :
Suizhou, China
Emission Standard :
Euro 4
Transmission Type :
Manual
Loading Weight of Flatbed :
3 Ton / 5 Ton / 8 Ton
Bearing Capacity :
Light
Condition :
New
Towing Tonnage :
3T
HS Code :
8705909990
Drive :
LHD or Rhd
Name :
Rollback Tow Truck
Fuel :
Diesel
Tow Type :
One Towing Tow
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Production Capacity :
500unit Per Month
Type :
Half Landing or Full Landing
Transport Package :
Bulk, RO-RO, Container
Engine for Option :
Cum-mins, Weichai, Yuchai
Description

New Jmc Brand 4X2 4 Ton Rollback Tow Wrecker Trucks

Product Description:

  1. Purpose of flatbed tow truck: wrecker/recovery truck/towing truck is used for towing broken cars,vehicle on road.With increasing ownership of private cars,wreckers are now widly used by government organization or towing company.
  2. Optional brand of flatbed tow truc:howo,Dongfeng,AC,JMC,Foton,Shacman.
  3. Spare parts of flatbed tow truc: Italy brand multi-way valve and balance valve; Gernamy Roxroth technology hydraulic cylinder and joint; imported sealing element; strengthed checked plate
  4. Capacity range of flatbed tow truc:3ton, 4ton, 5ton, 6ton, 8ton, 12ton, 16ton, 20ton, 25ton, 31ton, 40ton, 50ton
  5. The customers can choose to install the crane.
JMC brand 4x2 hydraulic winch 4 ton towing car flat bed wrecker truck with wheel lift ( half landing or full landing)







Basic information

Gross Vehicle Weight (kg)8210
Curb Weight (kg)4870
Rated Payload(kg)3340
Overall Dimension(mm)7440x2400x2400
Axle No.2
Cab Allowed Persons3
Wheelbase (mm)3815
F/R Suspension(mm)1155/2470
Max Speed(km/h)100
Appr/Dep Angle(º)12/20
Air conditionYES







Chassis Specifications

Chassis ModelJX1083TK25
Drive Type4x2
Axle Load(kg)3310/4965
Tyre Spec.7.50R16
Tyre No.6+ 1 spare
Leaf Spring No.8/7+7
Front/Rear Track (mm)1680/1640
Service brake typeCompressed air brake


Parking brake type

Spring energy, compressed air operating
on rear wheels









Superstructure of upper platform


Platform material

5mm stamping steel plate or
3mm punching steel plate can be choosed
Platform size (L X W mm)5600 x 2300
Platform max lifting3500
capacity (kg)
Platform landing gradient<= 11
Angle(º)
Hydraulic capstan winch-21 meters , or 30 meters can be choosed
steel string length (m)
Hydraulic capstain winch-can afford 4 tons
steel string tension
Rear towing Max afford (kg)3000kg
Auxiliary wheel1 set








Engine & Transmission specifications

Engine ModelJX4D30A5H
Engine BrandJMC automobile Co., Ltd
Fuel typeDiesel
Displacement (ml) / Power2892 / 112kw (152HP)

Engine Type

Turbocharged inter-cooled, 4 cylinder
in-line, water colling.
Emission StandardEuro V or III, IV can be selected
Rated speed2800rpm
Max Torque382N.m
Max torque(N.m/rpm)1800-2800rpm
Driving typeManual
No of transmission gears6 Forward, 1 Reverse
Remark1. With power assisted steering, auxiliary wheels, emergency rotation
lamp, spare tyre, hydrlic telescopic jack, wheel brace etc tools.
