Specifications
Payment Terms :
T/T,L/C
Model :
SIL
Supply Ability :
800 PCS/Month
Name :
Simple Reel Stand
Model Number :
SIL
MOQ :
1 PCS
Delivery Time :
3-7days
Price :
Negotiable
Rated Load :
10-50KN
Height Range :
450-1300mm
Packaging Details :
Plywood Case
Brand Name :
Suntech
Certification :
ISO
Place of Origin :
Ningbo
Description

Quick-Setup Heavy Duty Reel Holder for Power and Telecom Work


Product Overview

A heavy drum of cable is a hazard until it is properly seated — one wrong move and it can roll, tip or feed with jerky tension that damages the conductor. The SIL/SIK reel stand parks drums of 10kN to 50kN on a raised steel platform with an axle that turns freely, so the cable pays out in a steady, tangle-free stream. Height settings from 450mm to 1300mm adapt the stand to different drum sizes and work positions. High-strength steel keeps the frame solid, while foldable legs and tool-free setup make transport and deployment straightforward for line crews.

Technical Specifications

Item No.

Model

Rated Load (KN)

Height Adjustment (mm)

Weight (kg)

15191

SIL-1

10

450-650

22

15192

SIL-3

30

600-900

24

15193

SIL-5

50

900-1300

27

15201

SIK-3

30

600-900

30

15202

SIK-5

50

900-1300

44

15211

SIL-3A

30

600-900

28

15212

SIL-5A

50

900-1300

35

Applications

· Paying out cable and conductor during installation

· Conductor stringing on power line projects

· Industrial wiring and general cable handling

· Telecommunications cable deployment

Product Advantages

· Rock-Solid Seating — the robust frame and sturdy axle keep heavy reels from tipping, shifting or rolling while the drum spins.

· Steady Payout — the raised, free-turning axle smooths tension and eliminates jerky unspooling that can damage cable.

· Site Safety First — controlled feeding removes the danger of loose drums rolling free and cuts manual handling strain.

· Simple to Move and Run — high-strength steel folds for transport, sets up without special tools and needs minimal upkeep.
