40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material
40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material
40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material
40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material
40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material
40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material
40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material
40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material
Specifications
Brand Name :
BETTER
Model Number :
BDG
Place of Origin :
Xinxiang
MOQ :
1 Piece
Price :
US$3000-3500
Payment Terms :
L/C,T/T
Supply Ability :
50 Sets/Month
Delivery Time :
15-20 days
Packaging Details :
Single Package: Dimensions 300×200×100 cm; Gross Weight 1000 kg; Quantity per Package 1 unit.
Product Name :
Battery-Power Transfer Cart
Usage :
Heavy Duty Material Transportation
Load Capacity :
1-300ton
Special Function :
Anti-Explosion,Heat-Resistant,Lifting,Customized
Material :
Steel
Transport Package :
The Whole Cart Will Be Packed by Tarp.
Specification :
2000*2000*500
Trademark :
BETTER
Origin :
Xinxiang
HS Code :
84289090
Production Capacity :
50 Sets/Month
Description
40-Ton Rail Transfer Trolley for Heavy Material Handling
This heavy-duty 40-ton rail transfer trolley is specifically engineered for manufacturing facilities, warehouses, and logistics centers. Utilizing track guidance and motor-driven operation, it efficiently, safely, and reliably transports heavy materials, large workpieces, and standardized pallets along fixed routes. With its robust construction, simple operation, and low maintenance requirements, this equipment is ideal for optimizing in-plant logistics and connecting production processes.
Core Configuration
  • Load Capacity: Rated 40 tons with high-strength box beam structure optimized through finite element analysis
  • Rail System: Compatible with QU70-QU100 heavy-duty rails with customizable track gauge
  • Drive System: High-power AC variable-frequency motor for smooth operation and precise speed control
  • Power Supply: Standard safety sliding wire power supply with optional cable drum or low-voltage track power
  • Control Methods: Vehicle-mounted control box, wireless remote control, or driving operation
  • Platform Design: High-strength steel structure with anti-slip plates, T-shaped grooves, or custom tooling
40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material
Core Functions
  • Stable Heavy-Load Transportation: Low center of gravity design ensures smooth operation with 40-ton loads
  • Precise Positioning: ±5mm repeat docking accuracy for automated production line integration
  • Continuous Operation: 24-hour uninterrupted capability for high-frequency transportation
  • Easy Operation: Intuitive wireless or wired controls with minimal training required
Safety Features
  • Sound and light warning systems for operation alerts
  • Electrical protection with overcurrent, overload, phase loss, and leakage safeguards
  • Emergency stop buttons on both remote control and vehicle body
  • Automatic braking during signal loss
  • Dual parking protection with electromagnetic and manual mechanical brakes
Customization Options
  • Platform Types: Flat plates, concave platforms, V-shaped saddle seats, T-slot platforms, or powered roller decks
  • Function Expansion: Hydraulic lifting, platform rotation, lateral movement, automatic weighing, RFID material identification
  • Environmental Adaptability: Explosion-proof, high-temperature resistant, and corrosion-resistant versions available
40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material
Product Specifications
Model BDG-2t BDG-5t BDG-10t BDG-16t BDG-20t BDG-25t BDG-30t BDG-40t BDG-50t BDG-63t BDG-80t BDG-100t BDG-150t
Rated Load (t) 2 5 10 16 20 25 30 40 50 63 80 100 150
Table Size L (mm) 2000 3500 3600 4000 4000 4500 4500 5000 5500 5600 6000 6500 10000
Table Size W (mm) 1500 2000 2000 2000 2200 2200 2200 2500 2500 2500 2600 2800 3000
Table Size H (mm) 450 450 500 550 550 600 600 650 650 700 800 900 1200
Wheel Base (mm) 1200 2500 2600 2800 2800 3200 3200 3800 4200 4300 4700 4900 7000
Rail Inner Gauge (mm) 1200 1435 1435 1435 1435 1435 1435 1435 1435 1435 1800 2000 2000
Wheel Diameter (mm) 270 270 300 350 350 400 400 500 500 600 600 600 600
Wheel Quantity 4 4 4 4 4 4 4 4 4 4 4 4 8
Ground Clearance (mm) 50 50 50 50 50 50 50 50 50 75 75 75 75
Running Speed (m/min) 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-18
Motor Power (kw) 0.8 0.8 1.5 2.2 2.5 3 4 5.5 5.5 7.5 7.5 11 15
Transformer Power (KVA) 3 3 5 6.8 6.8 6.8 10 10 10 20 20 30 30
Transformer Quantity 1 1 1 1 1 1 1 1 1 1 1 1 1
Running Distance (m) 70 70 70 70 70 70 70 60 50 50 50 50 50
Max Wheel Load (KN) 14.4 25.8 42.6 64.5 77.7 94.5 110.4 142.8 174 221.4 278.4 343.8 265.2
Recommended Rail Model P15 P18 P18 P24 P24 P38 P38 P43 P43 P50 P50 QU100 QU100
Applications
  • Manufacturing Workshops: Transferring large components, molds, engines, and gearboxes between production lines
  • Warehousing & Logistics: Palletized goods transportation between shelving areas and loading docks
  • Metal Processing: Transfer of steel coils, plates, and ingots between storage and production areas
  • Heavy Machinery Manufacturing: Circulation of large structural components and equipment modules
  • Building Materials: Transportation of prefabricated wall panels, floor slabs, beams, and columns
40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material 40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material 40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material
Customization Inquiry
To customize your transfer cart, please provide the following information:
  • Type of materials or products to be transferred
  • Weight of the heaviest load
  • Dimensions (Length × Width × Height)
  • Trip frequency and shifts per day
  • Travel area specifications (rail/floor type, indoor/outdoor, path configuration)
  • Travel distance requirements
  • Any other relevant operating conditions
40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material
Key Advantages
  • Low Noise Operation: Minimal noise levels for improved working environment
  • Maximum Safety: Comprehensive safety features protecting operators and materials
  • Easy Operation: Intuitive controls with minimal training requirements
  • Easy Implementation: Operates on standard floors without complex installation
  • Versatile Capacity: Suitable for both small and extremely large loads up to 300 tons
40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material
Packaging & Shipping
40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material 40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material 40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material 40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material
Certifications
40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material 40ton Material Handling Equipment Rail Transfer Trolley for Handling Heavy Material
